Silver 1U rack server front panel with eight 2.5-inch drive bays

HP

HP ProLiant DL160 Gen9 1U rack server E5-2623 v3 16GB 2x 500GB SATA B140i

SKU CH-SQ00-QV2T7

1U rack server with Xeon E5-2623 v3 quad-core processor, 16GB DDR4 memory and two 500GB SATA drives on B140i software RAID

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 16GB

HDD 2 x 500GB

  • Quad-core Xeon E5-2623 v3 at 3 GHz for responsive compute
  • 16 GB DDR4 ECC memory with 16 DIMM slots for future expansion
  • Two 500 GB 7.2K SATA drives in 2.5-inch bays for immediate storage
  • B140i software RAID supporting levels 0, 1, 5 for data protection
  • Redundant hot-swap 550 W power supply keeps the server running

ProLiant DL160 Gen9 1U server

The HP ProLiant DL160 Gen9 is a 1U rack server built for balanced workloads. It ships with a single Intel Xeon E5-2623 v3 quad-core processor running at 3 GHz and 16 GB of DDR4 memory. Two 500 GB 7.2 K 2.5-inch SATA drives are installed on the B140i software RAID controller.

Buyers needing SATA-only RAID

This server suits environments that run SATA drives with RAID 0, 1 or 5 on the onboard B140i controller. It does not meet the needs of buyers who require hardware RAID or SAS connectivity, or builders who need more than two processors.

16 GB DDR4 maximum in this configuration

The unit arrives with 16 GB of DDR4 ECC registered memory, which matches the listed maximum installed capacity for this specific configuration. DDR4 is the only supported memory type; other DDR generations will not fit.

أبرز المميزات

  • Quad-core Xeon E5-2623 v3 at 3 GHz for responsive compute
  • 16 GB DDR4 ECC memory with 16 DIMM slots for future expansion
  • Two 500 GB 7.2K SATA drives in 2.5-inch bays for immediate storage
  • B140i software RAID supporting levels 0, 1, 5 for data protection
  • Redundant hot-swap 550 W power supply keeps the server running

المواصفات

BrandHP
SeriesProLiant
ModelProliant DL160 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity16GB
Memory Features16 DIMM slots, 8 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots16
Storage ControllerB140i Software RAID
HDD InterfaceSATA
SSD (Installed)No
Raid Level0,1,5
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports2 x Ports
Expansion SlotsCPU1 PCIe Riser 1: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Low Profile slot. Optional kit available to install Flexible LOM in slot 1. CPU 2 Riser (Optional): PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

إصدارات أخرى من هذا الطراز

5 أخرى من الفئة نفسها

نفس الفئة، بذاكرة أو مبرّد أو تردد مختلف — قارن قبل أن تقرر.

أسئلة حول هذا المنتج

Will the E5-2623 v3 processor and DDR4 memory work with my existing C610-chipset rack infrastructure?

The server uses the Intel C610 chipset and supports DDR4 ECC Registered modules up to 2400 MT/s, matching other Gen9 platforms that share the same chipset and memory architecture.

How can I verify the B140i controller and both 500 GB SATA drives are operating correctly after installation?

During POST the B140i option ROM will list the two 500 GB 7.2K 2.5-inch SATA drives and show the configured RAID level 0, 1 or 5; iLO health view also reports drive status and controller firmware version.

Which items ship with the 1U chassis and what must be sourced separately for a full deployment?

Included: single E5-2623 v3 processor, 16 GB DDR4, two 500 GB 2.5-inch SATA drives with trays, 550 W hot-swap power supply, Matrox G200 graphics, B140i SATA RAID. Not included: operating system, second processor, additional memory modules, extra drive trays or universal media bay.
