White mid-tower case with dual tempered-glass panels, vertical GPU orientation and white interior

HYTE

HYTE CS-HYTE-Y40-WW Y40 Snow White PC case

SKU CH-5942-A494H MPN CS-HYTE-Y40-WW

ATX mid-tower case with panoramic tempered glass, vertical GPU mounting via PCIe 4.0 riser, and pre-installed 120 mm fans

  • TypeATX Mid Tower
  • ColorWhite
  • Case MaterialABS / Steel / Tempered Glass
  • Motherboard CompatibilityATX / Micro ATX / Mini ITX
  • Side Panel2 x Sides Tempered Glass Panel
  • Internal 3.5" Drive Bays1

Options Y40 (Snow White)

الإصدارات المشطوبة موجودة، لكنها غير متوفرة هنا.

  • Vertical GPU mounting with PCIe 4.0 x16 riser included
  • Panoramic dual tempered glass panels showcase all-white interior
  • Top radiator support up to 360 mm for high-end liquid cooling
  • Pre-installed 120 mm fans at rear and bottom provide immediate airflow
  • Fits graphics cards up to 422 mm length and CPU coolers up to 183 mm height

Vertical GPU showcase

The HYTE Y40 Snow White is an ATX mid-tower case built around a panoramic tempered-glass layout that displays a graphics card in a vertical orientation. A PCI Express 4.0 x 16 riser cable is included so the GPU connects directly to the motherboard without extra purchases. The chassis uses ABS, steel and clear glass panels with an all-white interior finish.

Builders wanting a clean white aesthetic

This case suits builders who want a striking vertical GPU presentation and tool-less glass panels for easy access. It accepts ATX, Micro ATX and Mini ITX motherboards and provides one 3.5-inch bay plus two 2.5-inch bays for storage. Builds requiring more than four vertical expansion slots or a larger radiator than 360 mm at the top should consider other enclosures.

Included riser cable and two pre-installed fans

The bundled PCIe 4.0 riser cable enables the signature vertical mount while maintaining full 16-lane bandwidth for modern graphics cards. Two 120 mm fans rated at 1300 rpm are already fitted at the rear and bottom, delivering immediate airflow without additional parts. The white FE12 fans and clear glass preserve the monochrome theme throughout the build.

أبرز المميزات

  • Vertical GPU mounting with PCIe 4.0 x16 riser included
  • Panoramic dual tempered glass panels showcase all-white interior
  • Top radiator support up to 360 mm for high-end liquid cooling
  • Pre-installed 120 mm fans at rear and bottom provide immediate airflow
  • Fits graphics cards up to 422 mm length and CPU coolers up to 183 mm height

المواصفات

BrandHYTE
SeriesY40
ModelY40 SNOW WHITE
TypeATX Mid Tower
ColorWhite
Case MaterialABS / Steel / Tempered Glass
Motherboard CompatibilityATX / Micro ATX / Mini ITX
Side Panel2 x Sides Tempered Glass Panel
Internal 3.5" Drive Bays1
Internal 2.5" Drive Bays2
Expansion Slots4 Vertical, 7 low profile
Front Ports2 x USB 3.0?, 1 x USB 3.2 Type-C, 1 x Audio, ?
Fan OptionsTop: 3x 120mm
Side: 2x 120mm/140mm
Rear: 1x 120mm (1x 120mm, 1300 rpm included)
Bottom: 1x 120mm/140mm (1x 120mm, 1300 rpm included)
Pre-installed FansBottom - 1 x 120mm / Rear - 1 x 120mm
Radiator OptionsSide: up to 240, 280mm
Top: up to 360mm
Rear: 120mm
Max GPU Length422 mm length, 94 mm height (80 mm recommended)
Max CPU Cooler HeightUp to 183 mm tall
Max PSU LengthATX up to 224 mm
Dimensions21.15" x 12.88" x 20.67"
وزن الشحنة10.61 kg
أبعاد الطرد508 × 483 × 330 mm

إصدارات أخرى من هذا الطراز

1 أخرى من الفئة نفسها

نفس الفئة، بذاكرة أو مبرّد أو تردد مختلف — قارن قبل أن تقرر.

أسئلة حول هذا المنتج

Does the included PCIe 4.0 x16 riser cable need a motherboard with a PCIe 4.0 slot to work?

The riser cable is PCIe 4.0 rated, so it will run at 4.0 speeds when the motherboard slot supports it and fall back to 3.0 on older boards.

Will the two pre-installed 120 mm 1300 rpm fans connect to a 3-pin header on an older board?

Yes, the 4-pin PWM fans supplied with the case are backward compatible with 3-pin voltage-controlled headers.

How can I confirm the GPU is seated correctly in the vertical mount after building?

Check that the card sits flush in the vertical bracket, the riser cable is fully inserted at both ends, and the system posts with the GPU detected at PCIe 4.0 x16 in BIOS.
