Small green circuit board with a silver camera module and flat ribbon cable attached

KEHIPI

KEHIPI B0309 12MP IMX708 102° Fixed Focus Camera development board

SKU CH-3TDR-SM08Z

12MP IMX708 sensor with 102° fixed-focus lens, HDR output and cables for all Raspberry Pi boards

  • 12 MP IMX708 sensor delivers detailed images with 3 MP HDR output
  • 102° horizontal field of view captures wide scenes in a single frame
  • Fixed-focus lens removes the need for manual focus adjustment
  • Works with Raspberry Pi 5, 4, 3, 2 and Zero W boards
  • Includes 15-22 pin and 22-22 pin FPC cables for direct connection

KEHIPI B0309 12MP Camera Module

The KEHIPI B0309 is a 12 megapixel development camera built around the Sony IMX708 back-illuminated stacked CMOS sensor. It delivers a 102 degree horizontal field of view through a fixed focus lens and supports 3 megapixel HDR output. The board connects to Raspberry Pi systems using the standard 15 or 22 pin MIPI CSI interface and ships with both 15 to 22 pin and 22 to 22 pin FPC cables.

Makers needing wide fixed focus.

This module suits robotics, surveillance and edge AI prototypes that benefit from a constant wide angle perspective without focus adjustment. Buyers who need autofocus capability, a narrower field of view or motorised lens control should look at alternative camera boards because the fixed focus design cannot change its focal plane after installation.

Drops into any Raspberry Pi CSI slot

The board fits every Raspberry Pi model from the Pi 5 down to the Pi Zero W using the supplied FPC adapters, so no extra interconnect parts are required. Its fixed focus optics remove the need for focus calibration routines in software, freeing development time for image processing pipelines instead of lens tuning.

أبرز المميزات

  • 12 MP IMX708 sensor delivers detailed images with 3 MP HDR output
  • 102° horizontal field of view captures wide scenes in a single frame
  • Fixed-focus lens removes the need for manual focus adjustment
  • Works with Raspberry Pi 5, 4, 3, 2 and Zero W boards
  • Includes 15-22 pin and 22-22 pin FPC cables for direct connection

المواصفات

BrandArducam
ModelB0309

أسئلة حول هذا المنتج

Which Raspberry Pi boards accept the 15-22pin and 22-22pin FPC cables included with this B0309 module?

The two cables connect the IMX708 board to every Raspberry Pi model that uses a 15-pin or 22-pin MIPI CSI connector, covering Pi 5, Pi 4/4B, Pi 3, Pi 2 and Pi Zero W.

Will the fixed-focus 102° lens on this camera produce sharp images at the same distances as the official autofocus module?

Fixed focus is set at the factory for a broad depth of field; close-up detail will differ from the official autofocus version, so test your typical working distance before committing to a design.

How can I verify the IMX708 sensor is delivering 12 MP stills and 3 MP HDR output on my Pi?

Run libcamera-still at the maximum supported resolution and inspect the file dimensions; then enable the HDR capture path in the camera configuration and confirm the frame size drops to the 3 MP HDR mode.
