Compact 12.1 inch industrial all-in-one panel PC with IP65 front bezel and resistive touchscreen

partaker

partaker A2 12.1" all-in-one PC i7-6500U 16GB DDR3 256GB SSD

SKU CH-YQ1T-WM88Q

A 12.1-inch industrial panel PC with an IP65-rated resistive touchscreen, Intel Core i7-6500U processor, 16GB DDR3 memory and a 256GB SSD, running Windows 11 Pro in a fanless aluminium chassis

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity16GB DDR3
  • SSD256GB

Memory Capacity 16GB DDR3

  • IP65 front panel resists dust and water jets
  • Fanless aluminium alloy chassis runs silently
  • 5-wire resistive touchscreen rated for 35 million touches
  • Intel Core i7-6500U with 16 GB DDR3 and 256 GB SSD
  • Wide 0–50 °C operating range with SSD installed

Industrial panel PC for continuous use

The 12.1" TFT LED all-in-one unit combines an Intel Core i7-6500U processor with 16GB DDR3L memory and a 256GB SSD. Its IP65-rated front panel and five-wire resistive touchscreen operate reliably in 0 to 50°C environments. Windows 11 Pro is pre-installed for immediate deployment in factory automation, kiosk or machine-interface roles.

Fanless upgrade from active-cooled boxes

The aluminium-alloy passive chassis removes moving parts that fail in dusty or vibration-heavy settings. Two LAN ports, dual COM ports and both HDMI and VGA outputs replace older panels that offered fewer I/O options. The jump is worthwhile when silent operation, IP65 sealing and legacy serial connectivity are required together.

Sustained load with passive thermal management

Under continuous workloads the CPU maintains clocks up to 3.10 GHz while the fanless heatsink dissipates heat across the full chassis surface. Operating temperature stays within the rated 0 to 50°C range with the SSD installed. The 35-million-touch rated screen and 30,000-hour backlight life support round-the-clock shifts without thermal throttling or mechanical wear.

أبرز المميزات

  • IP65 front panel resists dust and water jets
  • Fanless aluminium alloy chassis runs silently
  • 5-wire resistive touchscreen rated for 35 million touches
  • Intel Core i7-6500U with 16 GB DDR3 and 256 GB SSD
  • Wide 0–50 °C operating range with SSD installed

المواصفات

ModelA2-PA-121TPC-CE5B(I76)-16G256G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity16GB DDR3
SSD256GB
HDDNo
Screen Size12.1"
TouchscreenYes

إصدارات أخرى من هذا الطراز

5 أخرى من الفئة نفسها

نفس الفئة، بذاكرة أو مبرّد أو تردد مختلف — قارن قبل أن تقرر.

أسئلة حول هذا المنتج

What is the panel cut-out size for the 306.8 mm wide A2 unit?

The opening hole measures 301 x 229 mm, so the panel cut-out must match those dimensions for embedded mounting.

How is the fanless i7-6500U panel PC mounted, and what step is often missed?

Mounting buckle kits are included for embedded, wall, desktop or cantilever installation; the step often missed is securing all buckles before connecting the 12 V DC power.

When will the resistive touchscreen on this 12.1" panel need replacement?

The touchscreen is rated for 35 million touches; replacement is needed once that count is reached or if the backlight drops below 30,000 hours of life.
