17 inch industrial all-in-one panel PC with IP65 front and fanless aluminium chassis

partaker

Partaker A8 17" i5-8265U 32GB 512GB all-in-one PC

SKU CH-WV8A-6ZH7Y

17-inch IP65 touchscreen all-in-one with i5-8265U, 32GB DDR4 and 512GB SSD for industrial use

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 8th Gen
  • GPU/VGA TypeIntel UHD Graphics
  • Memory Capacity32GB DDR4
  • SSD512GB

Memory Capacity 32GB DDR4

SSD 512GB

  • 256GB
  • 512GB
  • 1TB

HDD None

الإصدارات المشطوبة موجودة، لكنها غير متوفرة هنا.

  • IP65 front panel resists dust and water in harsh environments
  • 10-point capacitive touchscreen enables precise multi-touch control
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • 32 GB DDR4 and 512 GB SSD deliver responsive multitasking and fast storage
  • Intel Core i5-8265U up to 3.90 GHz handles demanding industrial workloads

Industrial all-in-one with IP65 front panel

The Partaker A8 integrates a 17 inch TFT LED display with a projected capacitive touchscreen into an aluminium alloy chassis rated IP65 on the front. An Intel Core i5 8265U processor and 32 GB of DDR4 memory run Windows 11 Pro from a 512 GB SSD. The fanless design targets factory floors, kiosks and embedded installations that need sealed, silent operation.

Sustained load on passively cooled U-series CPU

The i5 8265U operates at up to 3.90 GHz within a sealed enclosure that relies on the aluminium body for heat dissipation. Without active airflow the processor will throttle during prolonged heavy workloads to stay inside its thermal envelope. The system is rated for continuous 24/7 operation at ambient temperatures up to 50 °C when equipped with an SSD, making it suitable for steady-state industrial tasks rather than bursty compute peaks.

Silent thermals and 12 V DC power input

Passive cooling eliminates fan noise entirely, while the external 100-240 V AC to 12 V DC adapter keeps the internal power circuitry simple. Typical draw stays modest thanks to the U-series chip and SSD-only storage. The front panel brightness is 250 cd/m² with a 1000:1 contrast ratio, and the touch layer is rated for 200 million touches. Operating humidity spans 10 to 95 percent non-condensing at 40 °C.

أبرز المميزات

  • IP65 front panel resists dust and water in harsh environments
  • 10-point capacitive touchscreen enables precise multi-touch control
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • 32 GB DDR4 and 512 GB SSD deliver responsive multitasking and fast storage
  • Intel Core i5-8265U up to 3.90 GHz handles demanding industrial workloads

المواصفات

ModelA8-PA-170TPC-CE6A(I58)-32G512G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 8th Gen
GPU/VGA TypeIntel UHD Graphics
Memory Capacity32GB DDR4
SSD512GB
HDDNo
Screen Size17"
TouchscreenYes

إصدارات أخرى من هذا الطراز

5 أخرى من الفئة نفسها

نفس الفئة، بذاكرة أو مبرّد أو تردد مختلف — قارن قبل أن تقرر.

أسئلة حول هذا المنتج

How much heat and noise does the fanless aluminium chassis produce during continuous 24/7 operation?

The passive aluminium alloy cooling system runs completely silent and keeps the i5-8265U within its 0 – 50 °C operating range without any moving parts.

Which power input and mounting hardware are required before the unit will turn on?

A 12 V DC supply from the included 100-240 V AC adapter and the supplied embedded mounting buckle kit are needed for installation and automatic power-on after failure.

Can I add a Wi-Fi or 4G module using the internal expansion slot?

Yes, the mini PCIe slot with SIM socket accepts compatible Wi-Fi or 4G cards for wireless connectivity.
