Small white desktop firewall box with front port array

SonicWall

SonicWall TZ470 HA firewall appliance 02-SSC-6385

SKU CH-1GYV-Q1SJN MPN 02-SSC-6385

High-availability desktop firewall with 8x1GbE and 2x2.5GbE ports, supporting 1,000,000 sessions and 2,500 users for small organisations

  • TypeWired
  • Form FactorDesktop
  • StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHC
  • ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • SecuritySecurity Services Deep Packet Inspection services: Gateway A
  • Ports8x1GbE, 2x2.5GbE, 2 USB 3.0, 1 Console

Hardware TZ 470

Option High Availability

  • High-availability design with stateful sync for continuous protection
  • 8×1GbE and 2×2.5GbE ports plus 2 USB 3.0 for flexible connectivity
  • Deep packet inspection with gateway anti-virus, anti-spyware, intrusion prevention and DPI SSL
  • Supports up to 1,000,000 simultaneous sessions and 2,500 users
  • FIPS 140-2 Level 2 and ICSA certifications validate security effectiveness

High-Availability Firewall Appliance

The SonicWall TZ470 HA unit operates as the standby member in an active/standby pair with stateful synchronisation. It is built for small organisations and distributed enterprises that need a secondary appliance to maintain continuous protection if the primary unit fails.

Sustained Load Behaviour

The appliance supports up to 1000000 simultaneous sessions and 2500 users while drawing a maximum of 19.95W. Deep packet inspection services including gateway anti-virus, anti-spyware, intrusion prevention and DPI SSL run continuously across 8x1GbE and 2x2.5GbE ports without a separate power supply requirement beyond 100-240 VAC input.

Upgrade Context

This model replaces a single-appliance deployment when downtime cannot be tolerated and adds a second unit for automatic failover. The jump is worthwhile when an organisation already runs a TZ470 primary and needs matched hardware for stateful high availability, not for standalone use or capacity expansion alone.

أبرز المميزات

  • High-availability design with stateful sync for continuous protection
  • 8×1GbE and 2×2.5GbE ports plus 2 USB 3.0 for flexible connectivity
  • Deep packet inspection with gateway anti-virus, anti-spyware, intrusion prevention and DPI SSL
  • Supports up to 1,000,000 simultaneous sessions and 2,500 users
  • FIPS 140-2 Level 2 and ICSA certifications validate security effectiveness

المواصفات

BrandSONICWALL
SeriesTZ 470
ModelTZ 470 HA
Part Number02-SSC-6385
TypeWired
Form FactorDesktop
StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
SecuritySecurity Services
Deep Packet Inspection services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS): HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service
Application Visualization
Application Control
Capture Advanced Threat Protection
Ports8x1GbE, 2x2.5GbE, 2 USB 3.0,
1 Console
Simultaneous Sessions1000000
Maximum Users2500
VPNSite-to-site VPN tunnels: 150
IPSec VPN clients (maximum:) 5 (200)
SSL VPN licenses (maximum): 2 (150)
Encryption/authentication: DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange: Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN: RIP, OSPF, BGP
Certificate support: Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP
VPN features: Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported: Microsoft®, Windows 10
NetExtender: Mi
CertificationsFIPS 140-2 Level 2 (with Suite B), IPv6/USGv6, ICSA Network Firewall, ICSA Firewall Enterprise, ISCA
Network Antivirus / AntiMalware
ComplianceFCC Class B, ICES Class B, CE (EMC, LVD, RoHS), C-Tick,VCCI Class B, UL, cUL, TUV/GS, CB, Mexico CoC by UL,WEEE, REACH,BSMI, KCC/MSIP, ANATEL
Power Input100 - 240 VAC,
50-60 Hz, 3A
Max Power Consumption19.95W
FeaturesHigh availability: Active/Standby with stateful synchronization
Dimensions3.5x13.5x19 (cm)
1.8x5.3x7.5 (in)
Weight0.83 kg / 1.82 lbs
وزن الشحنة2.27 kg
أبعاد الطرد457 × 279 × 102 mm

إصدارات أخرى من هذا الطراز

5 أخرى من الفئة نفسها

نفس الفئة، بذاكرة أو مبرّد أو تردد مختلف — قارن قبل أن تقرر.

أسئلة حول هذا المنتج

How much power does the TZ470 HA draw at full load and what voltage range does it accept?

The appliance consumes up to 19.95 W and operates on 100 to 240 VAC at 50 to 60 Hz.

Which primary firewall must already be deployed for this High Availability unit to function as a standby device?

A SonicWall TZ470 primary unit is required; the HA appliance pairs with it for active/standby stateful synchronization.

Will the 2.5 GbE SFP+ ports on this HA unit link at full speed to my existing 1 GbE switches?

Yes, the 2.5 GbE ports auto-negotiate down to 1 GbE, so they connect to older 1 GbE gear without extra modules.
