Silver metal desktop switch with 16 RJ45 ports and LED indicators

Netgear Inc.

Netgear Inc. GS316P-100NAS 16-port Gigabit PoE+ network switch (115W)

SKU CH-8GT6-ZT36S MPN GS316P-100NAS

16-port Gigabit unmanaged switch with 115 W PoE+ budget, fanless and wall-mountable

  • FormatDesktop Wall Mountable Rack-mountable
  • StandardsIEEE 802.3 CSMA/CD 802.3az Energy Efficient Ethernet
  • Network MediaMedia Type Supported: Twisted Pair Ethernet Technology: Giga
  • Network Management TypeUnmanaged
  • Primary Ports16 x RJ45
  • Primary Port Speed10/100/1000Mbps

Model GS316P

  • 16 PoE+ ports deliver 115 W total power budget
  • Fanless design ensures silent operation in any environment
  • 16 Gigabit RJ-45 ports with auto-negotiation for simple setup
  • Desktop, wall or rack mounting hardware included
  • IEEE 802.3az Energy Efficient Ethernet reduces power consumption

16-port Gigabit PoE+ switch

The Netgear GS316P-100NAS is a 16-port unmanaged switch delivering Gigabit speeds over twisted-pair copper. It targets small offices and home networks that need to power wireless access points, IP cameras or VoIP phones without a separate power supply. Fanless construction keeps the unit silent in noise-sensitive rooms.

115 W total PoE+ budget

All sixteen RJ45 ports support IEEE 802.3at PoE+ at up to 30 W each, sharing a 115 W power budget that auto-balances per-port allocation based on device demand. The 54 V, 2.4 A DC input (130 W power adapter) feeds both switching and PoE loads. Uninterrupted PoE keeps endpoints powered during firmware updates or software reboots.

Desktop, wall or rack mounting included

The box supplies all hardware for desktop placement, wall mounting or rack installation, so the switch fits whatever space is available. LEDs show speed, link activity, PoE status, power and PoE-max conditions at a glance. Jumbo frames up to 9216 bytes, 1 MB buffer memory and a 4K MAC table handle bursty traffic without configuration.

Přednosti

  • 16 PoE+ ports deliver 115 W total power budget
  • Fanless design ensures silent operation in any environment
  • 16 Gigabit RJ-45 ports with auto-negotiation for simple setup
  • Desktop, wall or rack mounting hardware included
  • IEEE 802.3az Energy Efficient Ethernet reduces power consumption

Specifikace

BrandNETGEAR
Part NumberGS316P-100NAS
FormatDesktop
Wall Mountable
Rack-mountable
StandardsIEEE 802.3 CSMA/CD
802.3az Energy Efficient Ethernet
Network MediaMedia Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
Network Management TypeUnmanaged
Primary Ports16 x RJ45
Primary Port Speed10/100/1000Mbps
MAC Address Table4K
Jumbo Frames9216 bytes
Buffer Memory1MB
PoEYes
QoSYes
Layer2
LEDsSpeed, Link/Activity (Left), PoE (Right), Power, PoE Max
PowerDC Input/Power In: 54V, 2.4A (130W PA)
CertificationNDAA Compliant:
Yes
Environmentally Friendly:
Yes
Energy Efficiency Compliance:
Energy-related Products Directive (ErP)
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
TemperatureOperating: 0° to 40°C (32° to 104°F)
Storage: -20° to 70°C (-4° to 158°F)
HumidityOperating: 90% maximum relative humidity (RH), non-condensing
Storage: 95% maximum relative humidity (RH), non-condensing
FeaturesAuto-MDI/MDIX eliminates the need for crossover cables
LED indicators for ease of use
Energy-efficient technology for power savings
Fanless design for silent operation
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
Non-blocking switching architecture for maximum throughput at wire speed
Plug-and-play; no setup required
Durable and rugged metal case
Desktop, wall-mountable or rack-mountable (based on specific model)
Ideal for small office and home networks
Standards-based technology ensures interoperability with any standards-bas
Package ContentsGS316P Ethernet Switch
Power Adapter (localized to the country of sale)
Rubber Footpads for Desktop Installation
Wall Mount Kit and/or Rack Mount Kit
Installation Guide
Přepravní hmotnost0.88 kg
Rozměry balení287 × 102 × 28 mm

Další verze tohoto modelu

Dalších 4 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

What does the 115 W PoE budget mean when I plug in multiple cameras or access points?

The 115 W total budget is shared across all 16 PoE+ ports. Each port can deliver up to 30 W, so you can power several devices simultaneously until the combined draw reaches 115 W, after which additional ports will not receive power.

How does the Gigabit Ethernet interface limit real-world throughput on each port?

Each RJ45 port negotiates at 10, 100 or 1000 Mbps over twisted-pair cable. The 1000 Mbps ceiling is the maximum signalling rate; actual file-transfer speeds will be lower due to protocol overhead, cable quality and the performance of the connected device.

What mounting options are included for this desktop-sized switch?

The unit is designed for desktop placement and wall mounting. All necessary wall-mount hardware is supplied in the box, so you can secure it to a vertical surface without purchasing extra brackets.
