Silver 18.5 inch industrial all-in-one panel PC with resistive touchscreen

partaker

partaker A13-PA-190TPC-CE5B(I53) 18.5" industrial panel PC i5-3rd 8GB DDR3 256GB SSD

SKU CH-C5KG-0R1S9

18.5" IP65 front-panel industrial PC with 5-wire resistive touchscreen, Intel Core i5 3rd Gen, 8GB DDR3L and 256GB SSD

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 3rd Gen
  • CPU Name1.70GHz
  • GPU/VGA TypeIntel HD Graphics

GPU Intel HD Graphics

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

HDD None

Přeškrtnuté varianty existují, ale zde nejsou skladem.

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium-alloy cooling runs silently with no moving parts
  • 5-wire resistive touchscreen endures 35 million touches
  • 12 V DC input with auto power-on after outage
  • Intel Core i5 3rd Gen with 8 GB DDR3 and 256 GB SSD

18.5" industrial panel PC for embedded use

The Partaker A13-PA-190TPC-CE5B(I53) is an all-in-one computer with an 18.5" TFT LED display protected to IP65 on the front. It runs on an Intel Core i5 3rd Gen processor at 1.70GHz with 8GB DDR3L memory and a 256GB mSATA SSD. The unit includes a high-temperature 5-wire resistive touchscreen and fanless aluminium cooling for continuous operation.

Installation uses embedded buckle kits

The panel PC measures 460.3 x 282.4 x 54.5mm and weighs 4.5kgs, requiring a cut-out of 454 x 276.5mm for embedded fitting. It ships with Windows 10 Pro 64-bit pre-installed for immediate deployment. The fanless design eliminates moving parts, but the resistive touchscreen requires firm pressure and does not support multi-touch gestures.

Check 12V DC power and I/O compatibility before

The system operates on a 12V DC input with an included 100-240V AC adapter. Verify that your application can use the available ports: HDMI, VGA, four USB 2.0, LAN, audio in/out, two COM ports and a power switch. Expansion is limited to a mini PCIe slot with SIM holder for wireless modules. Operating temperature ranges from 0 to 50°C with the fitted SSD.

Přednosti

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium-alloy cooling runs silently with no moving parts
  • 5-wire resistive touchscreen endures 35 million touches
  • 12 V DC input with auto power-on after outage
  • Intel Core i5 3rd Gen with 8 GB DDR3 and 256 GB SSD

Specifikace

ModelA13-PA-190TPC-CE5B(I53)-8G256G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 3rd Gen
CPU Name1.70GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity8GB DDR3
SSD256GB
HDDNo
Screen Size18.5"
TouchscreenYes

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

How can I verify the 18.5 inch 1366 x 768 resistive touchscreen is responding correctly after installation?

Power on the unit, confirm Windows 10 Pro loads to the desktop, then tap the screen — the cursor should follow each press precisely across the full 1366 x 768 area.

What ships in the box and what must I source separately for this A13-PA-190TPC-CE5B(I53) panel PC?

Included are the panel PC, 12 V power supply, AC power cord, embedded buckle kits and warranty card; any Wi-Fi/4G mini-PCIe module, SIM card or extra mSATA / 2.5" SATA drive must be purchased separately.

Which configuration should I choose if I need the 8 GB DDR3L memory and 256 GB mSATA SSD already installed?

Select the A13-PA-190TPC-CE5B(I53)-8G256G model — it comes with 8 GB DDR3L SODIMM and a 256 GB mSATA SSD fitted, ready for 7 × 24 operation.
