Silver 21.5 inch industrial all-in-one panel PC with resistive touchscreen and fanless aluminium chassis

partaker

partaker A17 21.5" IP65 Industrial Panel PC i3-4th 1.90GHz 8GB DDR3 128GB SSD

SKU CH-V6NM-XB27S

21.5" IP65-rated industrial panel PC with Intel Core i3 4th Gen, 8GB DDR3 and 128GB SSD for 24/7 operation

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i3 4th Gen
  • CPU Name1.90GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

SSD

HDD None

  • None
  • 1TB

Přeškrtnuté varianty existují, ale zde nejsou skladem.

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium alloy chassis runs silently 24/7
  • 5" 1920 x 1080 resistive touchscreen withstands 35 million touches
  • Intel Core i3 4th Gen 1.90GHz with 8GB DDR3 and 128GB SSD
  • Wide 12V DC input plus HDMI, VGA, LAN, 2 COM, 4 USB for industrial integration

21.5" IP65 industrial panel PC

The Partaker A17 is a 21.5 inch all-in-one computer built for factory floors and outdoor kiosks. Its front panel meets IP65 protection against dust and water jets. An Intel Core i3 4th generation processor at 1.90 GHz drives Windows 10 Pro on 8 GB DDR3 memory and a 128 GB mSATA SSD. The 5-wire resistive touchscreen works with gloves or stylus in harsh environments.

Fanless aluminium chassis for continuous duty

Passive cooling eliminates moving parts, so the system runs silently and avoids dust ingestion during 24/7 operation. The CPU and chipset dissipate heat through the alloy body, maintaining stability across the 0 to 50 °C operating range with the fitted SSD. A watchdog timer of 255 levels can reset the unit automatically if software hangs. DC 12 V input accepts 100 to 240 V AC via the supplied adapter.

Verify mounting cut-out and legacy I/O needs

The embedded installation requires a rectangular opening of 522 x 315 mm; confirm your enclosure matches this cut-out before ordering. Video output uses VGA and HDMI ports, while serial equipment connects through two COM ports. Expansion is limited to a mini PCIe slot with a SIM holder for optional wireless modules. The panel brightness is 250 cd/m² with 80/80/80/80 viewing angles, so check ambient-light requirements for outdoor readability.

Přednosti

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium alloy chassis runs silently 24/7
  • 5" 1920 x 1080 resistive touchscreen withstands 35 million touches
  • Intel Core i3 4th Gen 1.90GHz with 8GB DDR3 and 128GB SSD
  • Wide 12V DC input plus HDMI, VGA, LAN, 2 COM, 4 USB for industrial integration

Specifikace

ModelA17-PA-215TPC-CE5A(I34)-8G128G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i3 4th Gen
CPU Name1.90GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
HDDNo
Screen Size21.5"
TouchscreenYes

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

How much power does the fanless aluminum cooling system draw during 24/7 operation?

The unit runs on a 12 V DC supply that accepts 100–240 V AC at 50–60 Hz; the passive aluminum chassis eliminates fan power entirely, so only the CPU, screen and peripherals consume energy.

Which cables and peripherals must I already have to get this panel PC running out of the box?

The box includes the panel PC, a 12 V power supply, an AC power cord and embedded mounting buckles; you will need to provide any HDMI or VGA display cables, USB keyboards or mice, Ethernet cable and serial devices yourself.

Will the 5-wire resistive touchscreen still register input when I wear industrial gloves?

The high-temperature 5-wire resistive panel is designed for gloved operation and rated for 35 million touches, making it suitable for continuous use with work gloves in industrial environments.
