Silver 12.1 inch industrial all-in-one panel PC with resistive touchscreen and fanless aluminium housing

partaker

Partaker A2-PA-121TPC-CE5B(I54) 12.1" industrial all-in-one PC

SKU CH-Z0XT-53V57

A 12.1 inch IP65-rated industrial panel PC with a resistive touchscreen, Intel Core i5 1.60GHz processor, 8GB DDR3L RAM, 256GB SSD and 1TB HDD, fanless aluminium construction and VESA 75 mounting

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 4th Gen
  • CPU Name1.60GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

  • 64GB
  • 256GB
  • 512GB

HDD 1TB

Přeškrtnuté varianty existují, ale zde nejsou skladem.

  • IP65 front panel resists dust and water jets
  • 1" resistive touchscreen rated for 200 million touches
  • Fanless aluminium chassis operates silently from 0 to 50 °C
  • Intel Core i5 1.60 GHz with 8 GB DDR3L handles industrial workloads
  • 256 GB mSATA SSD plus 1 TB 2.5" SATA HDD provide fast boot and ample storage

Industrial Panel PC

The Partaker A2-PA-121TPC-CE5B(I54) is a 12.1 inch all-in-one computer built for industrial environments. It integrates an Intel Core i5 4th Gen processor running at 1.60GHz with Intel HD Graphics 4400, 8GB of DDR3 memory, a 256GB SSD and a 1TB HDD. The IP65-rated front panel and high-temperature five-wire resistive touchscreen suit factory floors, automation cabinets and embedded kiosks where dust and moisture are present.

Fanless Thermal Design

An aluminium alloy chassis dissipates heat without moving parts, so the system runs silently in normal operation. The fanless construction eliminates bearing wear and reduces the ingress path for contaminants. Power is supplied through a 12V DC input fed by a 100-240V AC adapter, supporting automatic power-on after a power failure.

Sustained Load Behaviour

Operating temperature is rated 0 to 50°C when running from the SSD and 0 to 40°C with the mechanical HDD active. The watchdog timer offers a 255-level timeout to recover from software stalls during long shifts. With no fan to throttle, performance remains consistent as long as the enclosure ambient stays within the specified range.

Přednosti

  • IP65 front panel resists dust and water jets
  • 1" resistive touchscreen rated for 200 million touches
  • Fanless aluminium chassis operates silently from 0 to 50 °C
  • Intel Core i5 1.60 GHz with 8 GB DDR3L handles industrial workloads
  • 256 GB mSATA SSD plus 1 TB 2.5" SATA HDD provide fast boot and ample storage

Specifikace

ModelA2-PA-121TPC-CE5B(I54)-8G256G1TB
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 4th Gen
CPU Name1.60GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
SSD256GB
HDD1TB
Screen Size12.1"
TouchscreenYes

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

How do I mount the 12.1" unit in a panel cut-out, and which step is often missed?

Cut an opening of 301 x 229 mm, insert the unit from the front, and secure it with the supplied embedded buckle kits; the step often missed is fitting all four buckles evenly so the IP65 front seal seats correctly.

Which components will need replacement first during long-term operation?

The resistive touch screen is rated for 200 million touches and the LED backlight for 30000 hours minimum; the 2.5" SATA HDD has moving parts and typically wears out before the mSATA SSD or fanless cooling.

What thermal limit appears first when the system runs continuously at full load?

With the HDD installed the operating ceiling is 40 °C; with the SSD it rises to 50 °C, so the HDD temperature rating is the first constraint under sustained use.
