17 inch industrial all-in-one PC with IP65 front panel and fanless aluminium chassis

partaker

Partaker A8 17" IP65 i5-1135G7 16GB DDR4 256GB SSD all-in-one PC

SKU CH-7WD6-MF34B

A 17-inch IP65-rated all-in-one with a 10-point capacitive touchscreen, i5-1135G7 processor, 16GB DDR4 and 256GB SSD for industrial environments

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 11th Gen
  • GPU/VGA TypeIntel Iris Xe Graphics
  • Memory Capacity16GB DDR4
  • SSD256GB

Memory Capacity 16GB DDR4

SSD 256GB

HDD None

Přeškrtnuté varianty existují, ale zde nejsou skladem.

  • IP65 front-panel protection resists dust and water jets
  • 10-point projected capacitive touchscreen delivers 200 million touch durability
  • Fanless aluminum alloy cooling enables silent 24/7 operation
  • Intel Core i5-1135G7 with 16GB DDR4 handles industrial workloads
  • Dual LAN plus HDMI VGA and 2 COM ports support legacy and modern I/O

Industrial 17-inch touch panel PC

The Partaker A8 is a 17-inch all-in-one computer built around an Intel Core i5-1135G7 processor with 16GB of DDR4 memory and a 256GB SSD. Its IP65-rated front panel and fanless aluminium chassis are designed for continuous operation in industrial environments. The unit ships with Windows 11 Pro installed and includes a 10-point projected capacitive touchscreen.

Connectivity limited to HDMI VGA dual LAN

Video output is restricted to one HDMI and one VGA port, so only two external displays can be driven simultaneously. Networking relies on two wired LAN ports with no built-in wireless capability unless a WIFI6 module is added to the M.2 Key E slot. Expansion for 5G requires the M.2 Key B slot and a SIM card, while storage upgrades use one M.2 2260/2280 slot and one 2.5-inch SATA bay.

Verify mounting cut-out DC power and OS requirements

The embedded installation cut-out measures 380 by 315 millimetres and the unit weighs 4.6 kilograms, so the mounting surface must support that load. Power is supplied through a 12V DC input accepting 100 to 240V AC at 50 to 60Hz; no internal AC supply is present. The preloaded Windows 11 Pro licence suits Microsoft environments, but Linux Ubuntu is also supported if a different operating system is needed.

Přednosti

  • IP65 front-panel protection resists dust and water jets
  • 10-point projected capacitive touchscreen delivers 200 million touch durability
  • Fanless aluminum alloy cooling enables silent 24/7 operation
  • Intel Core i5-1135G7 with 16GB DDR4 handles industrial workloads
  • Dual LAN plus HDMI VGA and 2 COM ports support legacy and modern I/O

Specifikace

ModelA8-PA-170TPC-CE6A(I5B)-16G256G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 11th Gen
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity16GB DDR4
SSD256GB
HDDNo
Screen Size17"
TouchscreenYes

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

Should I choose the 16GB DDR4 256GB SSD version or add more memory later?

The unit ships with 16GB DDR4 and a 256GB SSD installed. Two SODIMM slots support DDR4-3200 up to 64GB total, so you can add modules later if workloads grow.

What does the i5-1135G7 up to 4.20 GHz mean for daily industrial tasks?

The quad-core processor with 8MB cache boosts to 4.20 GHz, giving responsive performance for HMI, data logging and light edge computing while the fanless chassis keeps noise at zero.

Which display interfaces are available and what resolution do they support?

HDMI and VGA ports drive external monitors; the built-in 17" panel runs at 1280 x 1024, and the Intel Iris Xe graphics can handle higher resolutions on the external outputs.
