Green circuit board with four blue USB 3.0 ports and a PCIe x1 edge connector, aluminum heatsink on top

Wadermoon

Wadermoon PCI-E 1X to 4 PCI-E USB 3.0 expansion card

SKU CH-96C1-ARNVY

Splits one PCIe x1 slot into four PCIe USB 3.0 ports for multi-GPU mining rigs

  • TypePCI Express to USB Card
  • External USB Ports4 Port
  • CompatibilityCompatible system: DOS / Linux / WinXP / Win7 / Win8 / Win10
  • Features?Easy Installation? No extra power cable needed, can be fixe
  • Dimensions4.72 x 2.64 x 2.24 inch
  • Weight50g
  • Expands one PCIe x1 slot into four PCIe USB 3.0 ports
  • Works with DOS, Linux, Windows XP through Windows 10
  • No extra power cable required for installation
  • Deep-sink aluminium heatsink keeps the card cool
  • Weighs 50g and measures 4.72 x 2.64 x 2.24 inch

One-to-four PCIe splitter for mining rigs

This Wadermoon adapter converts a single PCIe x1 slot into four PCIe USB 3.0 ports, letting miners attach multiple graphics cards to one motherboard. The card works with DOS, Linux, Windows XP, 7, 8 and 10, and includes an aluminium heatsink for thermal management. It draws power directly from the slot, so no extra cable is required.

Replaces single-slot risers when density matters

Instead of using one riser per GPU, this multiplier lets a single x1 lane feed four cards, saving motherboard slots and chassis space. The upgrade is worthwhile when the board cannot accept more physical x16 cards but the OS and driver stack can still enumerate additional GPUs. Windows 10 recognises up to eight cards, while Windows 7 stops at six.

Tool-free mounting with OS limits to watch

The board screws into a standard case bracket and needs no auxiliary power, making installation straightforward. Common issues include the USB-style ports carrying only PCIe signals, so they cannot connect ordinary USB devices. Motherboard BIOS limits and Windows GPU caps often require a modified driver or a Linux-based mining OS for full utilisation.

Přednosti

  • Expands one PCIe x1 slot into four PCIe USB 3.0 ports
  • Works with DOS, Linux, Windows XP through Windows 10
  • No extra power cable required for installation
  • Deep-sink aluminium heatsink keeps the card cool
  • Weighs 50g and measures 4.72 x 2.64 x 2.24 inch

Specifikace

BrandWadermoon
SeriesPCI-E 1X to External 4 PCI-E USB 3.0
TypePCI Express to USB Card
External USB Ports4 Port
CompatibilityCompatible system: DOS / Linux / WinXP / Win7 / Win8 / Win10.
Features?Easy Installation? No extra power cable needed, can be fixed to the case, it’s easy and convenient to settle and install.
Dimensions4.72 x 2.64 x 2.24 inch
Weight50g
Package Contents1 PCI-E USB 3.0 adapter riser card.

Otázky k tomuto produktu

What are the board dimensions for case clearance?

The adapter measures 4.72 x 2.64 x 2.24 inch and weighs 50g, so check that your chassis has room for a card this size before ordering.

How is the card powered, and what mistake do builders make?

No extra power cable is required; the board draws power from the PCIe x1 slot, but the four USB 3.0 ports carry PCIe signals only — do not plug ordinary USB devices into them.

What component may need attention after extended mining use?

The aluminum IC heat radiator handles cooling; if temperatures rise over time, clean the heatsink fins and verify the riser remains firmly seated in the slot.
