ASUSTOR AS6808T 8-bay NAS 16GB DDR5 ECC Ryzen V3C14 2.3GHz
An eight-bay desktop NAS with four M.2 slots, dual 10GbE and dual 5GbE ports, two USB4 ports, a quad-core Ryzen CPU at 2.3 GHz, and 16 GB DDR5 ECC memory expandable to 64 GB
- TypeDesktop NAS
- Ports2 x 10GbE
- Port RJ-452 x 2.5 GbE
- Port USB2x USB4+3x USB 3.2 Gen 2 Type-A
- HDD Interface8Bay SATA HDD+4Bay M.2 SSD
- Form Factor8Bay SATA HDD + 4*M.2 SSD
- Quad-core Ryzen V3C14 reaches 3.8 GHz turbo for responsive multitasking
- 16 GB DDR5-4800 ECC memory protects data integrity under heavy loads
- Four M.2 slots with PCIe 4.0 double NVMe SSD throughput
- Two USB4 ports at 40 Gbps plus three USB 3.2 Gen 2 ports at 10 Gbps
- Dual 10 GbE and dual 5 GbE ports enable high-speed network access
Eight-bay desktop NAS with Ryzen V3C14
The AS6808T is an eight-bay desktop NAS powered by a quad-core AMD Ryzen Embedded V3C14 processor at 2.3 GHz with 3.8 GHz turbo. It ships with 16 GB of DDR5-4800 ECC memory, expandable to 64 GB across two slots. The unit supports ADM 5.0 and offers RAID 0, 1, 5, 6, 10 and JBOD across up to 192 TB of raw capacity.
Check drive count, network and USB needs
Verify you can populate up to eight 3.5-inch SATA drives and four M.2 NVMe SSDs for the full 192 TB limit. Confirm your switch or router has 10 GbE or 5 GbE ports to use the dual 10 GbE and dual 5 GbE RJ-45 links. Ensure USB 4 or USB 3.2 Gen 2 Type-A peripherals match the two 40 Gbps and three 10 Gbps ports. The unit runs on 100-240 VAC 50/60 Hz mains power.
Replaces smaller NAS or direct-attached storage
This system replaces four-bay or six-bay NAS units when you need more drive bays, ECC memory and multi-gigabit Ethernet in one chassis. The jump is worth it for workloads that saturate 2.5 GbE links, require hardware-accelerated transcoding or need PCIe 4.0 NVMe caching. It is not suited for buyers who only need two drive bays or single-gigabit connectivity.
Besonderheiten
- Quad-core Ryzen V3C14 reaches 3.8 GHz turbo for responsive multitasking
- 16 GB DDR5-4800 ECC memory protects data integrity under heavy loads
- Four M.2 slots with PCIe 4.0 double NVMe SSD throughput
- Two USB4 ports at 40 Gbps plus three USB 3.2 Gen 2 ports at 10 Gbps
- Dual 10 GbE and dual 5 GbE ports enable high-speed network access
Technische Daten
| Brand | Asustor |
|---|---|
| Series | LockerStor Gen5 |
| Model | AS6808T |
| Type | Desktop NAS |
| Ports | 2 x 10GbE |
| Port RJ-45 | 2 x 2.5 GbE |
| Port USB | 2x USB4+3x USB 3.2 Gen 2 Type-A |
| HDD Interface | 8Bay SATA HDD+4Bay M.2 SSD |
| Form Factor | 8Bay SATA HDD + 4*M.2 SSD |
| Operating System | ADM 5.0 |
| Processor | AMD Ryzen |
| Installed Memory | 16GB |
| Max Memory Capacity | 64GB |
| Memory Slot | 2 |
| Included HDD Capacity | N/A |
| Max Capacity | 192TB |
| RAID | RAID 0, 1, 5, 6, 10, and JBOD |
| Environment Remote Control | HDD, cooling fan, CPU temperature, network status |
| LEDs | Power, HDD (Hard Disk Drive), LAN (10/100) |
| Power | 100-240 VAC 50/60Hz |
| Power Consumption | 68.68W |
| Temperature | 0°C - 40 °C |
| Humidity | 5-95% R.H |
| Usage | Backup & stream media through personal cloud |
| Dimensions | 12.7 x 14.9 x 13.36 |
| Weight | 19.25 |
| Sports Team | 2 Piece |
| Versandgewicht | 9.16 kg |
| Paketgröße | 400 × 368 × 356 mm |
Fragen zu diesem Artikel
Does the AS6808T ship with any drives or must I supply all eight SATA bays and four M.2 slots myself?
The unit is sold diskless; you provide up to eight SATA drives and up to four M.2 NVMe SSDs for a combined raw capacity of 192 TB.
Should I pick the 16 GB model or plan to upgrade to the 64 GB maximum for virtualization workloads?
The installed 16 GB DDR5-4800 ECC module handles most workloads; add a second module later only if your VMs or containers regularly exceed that footprint.
How does the 2.3 GHz Ryzen V3C14 perform when the 10 GbE and USB4 ports are saturated simultaneously?
The quad-core CPU boosts to 3.8 GHz, giving enough headroom to drive both 10 GbE links and two 40 Gbps USB4 connections without becoming the bottleneck.
