Two green DDR3 SODIMM sticks, 204-pin, no heat spreader

Computer Memory Solutions

Computer Memory Solutions 8GB (2×4GB) DDR3-1333 CL9 SODIMM memory upgrade

SKU CH-N3HD-EE47X

DDR3 SODIMM kit adding 8GB across two 4GB modules at 1333MHz CL9 for HP Pavilion dv7-6166nr, dv7-6165us and dv7-6168nr notebooks

  • Capacity8GB (2 x 4GB)
  • Type204-Pin DDR3 SO-DIMM
  • SpeedDDR3 1333 (PC3 10600)
  • CAS LatencyCL9
  • Timing9-9-9
  • Voltage1.5V
  • 8 GB total capacity from two matched 4 GB modules
  • DDR3-1333 speed with CL9 timing for responsive performance
  • 5 V operation keeps power draw low
  • 204-pin unbuffered non-ECC SO-DIMM fits the listed HP Pavilion models
  • Lifetime warranty from Computer Memory Solutions when purchased directly

Compatibility and capacity

This kit provides 8GB of DDR3 memory in two 4GB SODIMM modules for select HP Pavilion dv7 notebooks. It is built for owners of the dv7-6165us, dv7-6166nr or dv7-6168nr who want to reach the platform's supported limit. The modules run at 1333MHz with CL9 timing at 1.5V. They install directly into the two available 204-pin slots.

Who should consider this

This upgrade suits users restoring or maintaining one of the three listed dv7 models and who need the full 8GB capacity the chipset allows. Buyers with other laptops, desktops or servers cannot use these SODIMMs. The kit is non-ECC and unbuffered, so it will not work in systems that require registered or error-correcting modules. Anyone needing more than 8GB must choose a different platform.

DDR3-1333 CL9 SODIMM specification

The decisive specification is DDR3-1333 (PC3-10600) with CL9 latency in 204-pin SODIMM form factor. The memory bus may operate at 1066MHz depending on the installed processor, per HP documentation. A 64-bit operating system is required to address the full 8GB. Verify your exact model number before ordering.

Besonderheiten

  • 8 GB total capacity from two matched 4 GB modules
  • DDR3-1333 speed with CL9 timing for responsive performance
  • 5 V operation keeps power draw low
  • 204-pin unbuffered non-ECC SO-DIMM fits the listed HP Pavilion models
  • Lifetime warranty from Computer Memory Solutions when purchased directly

Technische Daten

BrandComputer Memory Solutions
ModelCM5126410600SOSRH
Capacity8GB (2 x 4GB)
Type204-Pin DDR3 SO-DIMM
SpeedDDR3 1333 (PC3 10600)
CAS LatencyCL9
Timing9-9-9
Voltage1.5V
ECCNo
Buffered/RegisteredUnbuffered
Rank1Rx8
ChipsetMajor Brand Chipset
Heat SpreaderNo
Compatible SystemHp Pavilion Dv7-6166Nr, Dv7-6165Us, Dv7-6168Nr
Package Content2 Memory RAM Sticks

Fragen zu diesem Artikel

Will the 1333 MHz rating actually run at that speed in my HP Pavilion dv7-6166nr?

The system documentation notes the memory bus may run at 1066 MHz depending on the processor installed, so the modules will operate at the lower speed if the CPU limits it.

The kit is labelled PC3-10600; what bandwidth does that represent in practice?

PC3-10600 corresponds to a peak transfer rate of 10600 MB/s, but the platform may cap throughput at 8500 MB/s if the bus runs at 1066 MHz.

What physical slot and pin count do these sticks need to fit the laptop?

They are 204-pin DDR3 SO-DIMM modules, the standard form factor for the compatible HP Pavilion dv7 models listed.
