Green development board with ESP32-P4 chip, USB OTG 2.0 port, MIPI connectors and GPIO header pins

LORDWORLD

LORDWORLD ESP32-P4-Core-DEV-KIT-M Development Board 32MB PSRAM 32MB Flash USB OTG 2.0 HS

SKU CH-2JNA-HSAK4

RISC-V development board with 32 MB PSRAM, 32 MB flash, MIPI CSI and DSI interfaces, and USB OTG 2.0 HS for multimedia prototypes

  • High-performance RISC-V MCU for multimedia and edge computing
  • MIPI-CSI and MIPI-DSI interfaces enable camera and display development
  • USB OTG 2.0 HS plus extensive peripherals for system design
  • 32MB PSRAM and 32MB NOR Flash support graphics and data buffering
  • Secure Boot, Flash Encryption and cryptographic accelerators protect embedded applications

RISC-V MCU board for multimedia prototypes

The LORDWORLD ESP32-P4-Core-DEV-KIT-M is a high-performance RISC-V development board built around the ESP32-P4 microcontroller. It targets developers working on multimedia development, embedded control, edge computing and HMI prototype projects. The board integrates 32MB PSRAM inside the chip package and provides 32MB of onboard NOR Flash for graphics, audio and data buffering tasks.

Upgrade path from boards lacking MIPI

This board adds MIPI-CSI and MIPI-DSI interfaces for camera input and display output, plus USB OTG 2.0 HS for faster host or device connectivity. The jump is worth it when a project needs integrated camera and display pipelines, expanded peripheral interfaces such as SPI, I2C, I2S, UART, TWAI, ADC, LED PWM, MCPWM and RMT, or the security suite of Secure Boot, Flash Encryption, cryptographic accelerators and TRNG.

Suits developers building secure embedded

Engineers prototyping image processing, visual interaction or embedded multimedia applications will benefit from the MIPI interfaces and memory resources. It also fits controller testing and IO expansion work. Developers who do not require camera or display interfaces, or who need a different MCU architecture, should look at alternative boards.

Besonderheiten

  • High-performance RISC-V MCU for multimedia and edge computing
  • MIPI-CSI and MIPI-DSI interfaces enable camera and display development
  • USB OTG 2.0 HS plus extensive peripherals for system design
  • 32MB PSRAM and 32MB NOR Flash support graphics and data buffering
  • Secure Boot, Flash Encryption and cryptographic accelerators protect embedded applications

Technische Daten

BrandLORDWORLD

Fragen zu diesem Artikel

What board size and mounting holes does the ESP32-P4-Core-DEV-KIT-M have for enclosure fitting?

The development board uses a standard maker form factor with corner mounting holes compatible with M3 hardware for secure enclosure installation.

How is the board powered and programmed via the USB OTG 2.0 HS port, and what driver step is often missed?

Connect the USB OTG 2.0 HS port to a host PC; the board enters download mode automatically when the BOOT button is held during reset, and the ESP-IDF USB CDC driver must be installed for serial console access.

Will the onboard 32MB NOR Flash or 32MB PSRAM need replacement during long-term deployment?

Both memories are soldered directly to the board and rated for the product lifetime; no user replacement is required or possible.
