Green circuit board with four blue USB ports and acrylic mounting plate

LORDWORLD

LORDWORLD PCIe to 4-Ch USB 3.2 Gen1 Board (C) development board

SKU CH-TRG9-V9JTD

Adds four USB 3.2 Gen1 ports to a Raspberry Pi 5 via PCIe with per-port power control and dual supply options

  • Adds four USB 3.2 Gen1 ports for faster peripheral access
  • Theoretical 500 MB/s throughput speeds up data transfers
  • Independent power control per port lets you manage connected devices
  • Dual power input options via 2-pin header or 3-pin connector
  • Acrylic base plate keeps the board stable during operation

PCIe to Four USB 3.2 Gen1 Ports

This LORDWORLD development board adds four USB 3.2 Gen1 channels to a Raspberry Pi 5 through its PCIe interface. Each port supports up to 500 MB/s theoretical throughput for high-speed peripheral connectivity. The board includes an acrylic mounting plate for secure installation.

Makers needing independent port power control

Builders who want to toggle power on each USB port individually via software commands will benefit from the four-channel independent power management. Users requiring internal storage expansion or different interface types should consider other expansion options.

Four-channel independent power switching

Each USB port can be turned on or off separately through command control, allowing precise power management for connected devices. The board accepts power through either a 2-pin header or a 3-pin connector for flexible integration.

Besonderheiten

  • Adds four USB 3.2 Gen1 ports for faster peripheral access
  • Theoretical 500 MB/s throughput speeds up data transfers
  • Independent power control per port lets you manage connected devices
  • Dual power input options via 2-pin header or 3-pin connector
  • Acrylic base plate keeps the board stable during operation

Technische Daten

BrandLORDWORLD

Fragen zu diesem Artikel

How can I verify the board is delivering 500 MB/s transfers after connecting it to my Raspberry Pi 5?

Run a disk-speed test such as `hdparm -t` or `dd` against a USB 3.2 Gen1 drive attached to one of the four ports; sustained reads near 500 MB/s confirm the link is operating at the expected 5 Gbps rate.

What comes in the box and what extra parts are needed to power the four USB ports?

The package includes the PCIe-to-4-channel USB 3.2 Gen1 board and an acrylic mounting plate; you must supply either a 2-pin header or a 3-pin connector to provide external power to the ports.

Which version of this board should I choose if I want to run eight USB ports on a Raspberry Pi 5?

This single board adds four USB 3.2 Gen1 ports; installing two of them side by side on the Pi 5's PCIe interface expands the system to eight high-speed ports.
