MAIWO
MAIWO K35262C Dual Bay 3.5" SATA RAID Enclosure with Fan
A dual-bay 3.5" SATA RAID enclosure with a built-in cooling fan, aluminium shell, 10 Gbps USB 3.1 connection and four RAID modes supporting up to 36 TB total capacity
- TypeUSB Docking Station
- AC AdapterNo
- MaterialAluminum
- External InterfaceUSB 3.1
- HDD Count SupportedDual bay 3.5" HDD Docking Station USB3.1 to SATA w
- Number of Bay2 Bay
- Dual 3.5" bays hold up to 36TB total
- USB 3.1 Gen 2 reaches 10Gbps transfer speed
- Built-in fan plus aluminium shell keeps drives cool
- Four RAID modes cover backup, speed or capacity
- 48W power adapter delivers stable 12V 4A supply
Dual-Bay 3.5" SATA RAID Enclosure
The MAIWO K35262C accepts two 3.5-inch SATA I, II or III hard drives up to 18TB each for a combined 36TB. Aluminium construction and a built-in fan dissipate heat during sustained operation. A 48W power adapter supplies stable current to both bays. Tool-free trays make drive swaps quick.
USB 3.1 Gen 2 10Gbps Interface Limit
The USB 3.1 Gen 2 connection tops out at 10Gbps, while each SATA III drive can deliver 6Gbps. In RAID 0 the combined throughput can saturate the link, so sustained transfers will not exceed the USB ceiling. UASP support reduces protocol overhead but cannot raise the physical bandwidth. RAID 1 and Large modes operate well within the limit.
Hardware RAID Mode Selector
A physical switch chooses between RAID 0, RAID 1, Large (JBOD) and Normal (independent) modes without software. The enclosure presents the selected array to the host as a single volume or two separate drives. No driver installation is required on Windows, macOS or Linux. Mode changes require a reboot to take effect.
Besonderheiten
- Dual 3.5" bays hold up to 36TB total
- USB 3.1 Gen 2 reaches 10Gbps transfer speed
- Built-in fan plus aluminium shell keeps drives cool
- Four RAID modes cover backup, speed or capacity
- 48W power adapter delivers stable 12V 4A supply
Technische Daten
| Brand | MAIWO |
|---|---|
| Model | K35262C |
| Type | USB Docking Station |
| AC Adapter | No |
| Material | Aluminum |
| External Interface | USB 3.1 |
| HDD Count Supported | Dual bay 3.5" HDD Docking Station USB3.1 to SATA w |
| Number of Bay | 2 Bay |
| Maximum Capacity (per Bay) | Up to 18TB |
| Fan | Yes |
| Power | 12V4A |
| Specifications | Supports up to 36TB Capacity USB3.1 Transfer Speed up to 10Gbps Fast Heat Dssipation System with Cooling Fan 4 Raid Modes: The hard drive enclosure has 4 Raid modes, no matter you want to back up your data, quickly transfer data, read&write two HDD at the same time or expand your storage capacity, this enclosure is what you needed, easy to set the modes |
| Features | Supports up to 36TB Capacity USB3.1 Transfer Speed up to 10Gbps Fast Heat Dssipation System with Cooling Fan 4 Raid Modes: The hard drive enclosure has 4 Raid modes, no matter you want to back up your data, quickly transfer data, read&write two HDD at the same time or expand your storage capacity, this enclosure is what you needed, easy to set the modes |
| Package Contents | 1x Dual Bay Raid Docking Station for 3.5inch SATA HDD with Cooling Fan |
Fragen zu diesem Artikel
Should I choose the 18TB per bay limit or the 36TB total when buying drives?
Each bay accepts up to 18TB, so two drives give a combined 36TB ceiling; pick drives that suit your capacity and redundancy plan.
What does the 10Gbps USB 3.1 rating deliver inside my computer?
The USB 3.1 Gen 2 link caps at 10Gbps, while the internal SATA III connection runs at 6Gbps, so real-world throughput is limited by the slower SATA side.
Which interface standard controls the speed between the enclosure and my PC?
The enclosure uses a USB 3.1 Gen 2 Type-C connection rated at 10Gbps, and it includes both C-to-C and C-to-A cables for compatibility.
