Silver 15-inch all-in-one panel PC with flat projected capacitive touchscreen and aluminium fanless chassis

partaker

Partaker A4-PA-150TPC-CE6A(I54) 15" all-in-one PC, Core i5 4th Gen 1.60GHz, 8GB DDR3, 512GB SSD

SKU CH-H34J-K867P

A 15 inch IP65 industrial panel PC with 10 point capacitive touch, Intel Core i5 4th Gen 1.60GHz, 8GB DDR3L, 512GB SSD, fanless aluminium chassis and VESA 75 mounting

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 4th Gen
  • CPU Name1.60GHz
  • GPU/VGA TypeIntel HD Graphics 4400

GPU Intel HD Graphics 4400

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 512GB

HDD None

  • None
  • 1TB

Durchgestrichene Varianten existieren, sind hier aber nicht vorrätig.

  • IP65 front panel resists dust and water ingress
  • 10-point capacitive touch enables precise multi-finger control
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • 512 GB SSD plus spare SATA bay for storage expansion
  • VESA 75 mount and embedded brackets simplify installation

15-inch industrial panel PC

The Partaker A4-PA-150TPC-CE6A(I54) integrates a 15-inch TFT LED display with an Intel Core i5 4th Gen 1.60GHz processor, 8GB DDR3L memory and a 512GB SSD in a fanless aluminium chassis. It targets automation engineers and system integrators who need a compact Windows 10 Pro or Ubuntu platform with IP65 front protection for factory floors, kiosks or embedded machinery.

Fanless thermal design and DC power

An aluminium-alloy heatsink dissipates heat without moving parts, so the unit runs silently across a 0 to 50°C operating range with the fitted SSD. The system draws power from an external 12V DC supply that accepts 100-240V AC input, eliminating internal PSU heat and reducing failure points in continuous 24/7 operation.

Expansion and mounting flexibility

A full-size Mini PCIe slot with SIM holder adds Wi-Fi or 4G connectivity, while dual COM ports, twin USB 3.0 and USB 2.0 ports, HDMI, VGA and audio I/O cover legacy and modern peripherals. VESA 75 mounting holes and supplied embedded buckle kits enable panel, wall, desktop or cantilever installation without extra brackets.

Besonderheiten

  • IP65 front panel resists dust and water ingress
  • 10-point capacitive touch enables precise multi-finger control
  • Fanless aluminium chassis runs silently in noise-sensitive areas
  • 512 GB SSD plus spare SATA bay for storage expansion
  • VESA 75 mount and embedded brackets simplify installation

Technische Daten

ModelA4-PA-150TPC-CE6A(I54)-8G512G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 4th Gen
CPU Name1.60GHz
GPU/VGA TypeIntel HD Graphics 4400
Memory Capacity8GB DDR3
SSD512GB
HDDNo
Screen Size15"
TouchscreenYes

Andere Versionen dieses Modells

5 weitere aus dieser Serie

Gleiche Familie, unterschiedlicher Speicher, Kühler oder Takt — vergleichen Sie, bevor Sie sich entscheiden.

Fragen zu diesem Artikel

How do I mount the 15" panel using the embedded buckle kits and keep the IP65 seal intact?

Cut the opening hole to 1024 x 768 mm, insert the unit from the front, tighten the supplied buckle kits evenly around the frame, and verify the gasket sits flat so the front maintains its IP65 rating.

Which memory module do I need when the 8GB DDR3L SODIMM eventually fails?

Replace it with a single 204-pin SODIMM DDR3L 1333/1600 module; the board has one slot and the maximum supported capacity is 8GB.

At what temperature does the fanless aluminium chassis start to throttle the Core i5 under continuous load?

The operating range tops out at 50 °C with the installed SSD; sustained loads above that ambient temperature will trigger thermal throttling first.
