15.6 inch industrial all-in-one panel PC with IP65 front bezel and resistive touchscreen

partaker

Partaker A7 15.6" all-in-one PC i7-6500U 8GB DDR3 512GB SSD 1TB HDD

SKU CH-410E-2QYJ0

A 15.6" IP65-rated industrial all-in-one with an i7-6500U, 8GB DDR3, 512GB SSD and 1TB HDD for continuous operation

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity8GB DDR3
  • SSD512GB

Memory Capacity 8GB DDR3

  • IP65 front panel withstands dust and water jets in harsh environments
  • Intel Core i7-6500U up to 3.10 GHz handles continuous 7×24 workloads
  • Fanless aluminium alloy chassis runs silently with passive cooling
  • 512 GB SSD plus 1 TB HDD provides fast boot and large local storage
  • 5-wire resistive touchscreen rated for 35 million touches operates at high temperature

Industrial panel PC for 24/7 environments

The Partaker A7 is a 15.6" all-in-one computer built around an Intel Core i7-6500U processor with 8GB DDR3L memory, a 512GB SSD and a 1TB HDD. Its IP65-rated front panel and high-temperature five-wire resistive touchscreen are designed for continuous operation in factories, kiosks or outdoor cabinets. Windows 11 Pro is pre-installed for immediate deployment.

Fanless cooling and embedded mounting simplify

An aluminium-alloy passive heatsink removes the need for moving parts, eliminating fan noise and a common failure point in dusty settings. The package includes embedded buckle kits that secure the unit into a 386.5 x 236 mm cut-out, while a 12 V DC power supply supports 100-240 V AC input. Two LAN ports, two COM ports, HDMI and VGA give flexible connectivity for legacy and modern peripherals.

Installation fits standard panel cut-outs

The chassis measures 392.6 x 241.7 x 54.5 mm and weighs 3.4 kg, matching common industrial enclosure dimensions. A single 12 V DC jack powers the system, so only one cable crosses the panel seal. Operators should verify the 0-50 °C operating range with SSD or 0-40 °C with the mechanical HDD, and ensure the mounting surface is flat to maintain the IP65 seal.

Besonderheiten

  • IP65 front panel withstands dust and water jets in harsh environments
  • Intel Core i7-6500U up to 3.10 GHz handles continuous 7×24 workloads
  • Fanless aluminium alloy chassis runs silently with passive cooling
  • 512 GB SSD plus 1 TB HDD provides fast boot and large local storage
  • 5-wire resistive touchscreen rated for 35 million touches operates at high temperature

Technische Daten

ModelA7-PA-156TPC-CE5A(I76))-8G512G1TB
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity8GB DDR3
SSD512GB
HDD1TB
Screen Size15.6"
TouchscreenYes

Andere Versionen dieses Modells

5 weitere aus dieser Serie

Gleiche Familie, unterschiedlicher Speicher, Kühler oder Takt — vergleichen Sie, bevor Sie sich entscheiden.

Fragen zu diesem Artikel

Will the 15.6 inch resistive touchscreen need replacement after heavy industrial use?

The five-wire resistive touchscreen is rated for 35 million touches and the LED backlight has a minimum life of 30000 hours, so replacement is unlikely during normal service life.

What thermal limit appears first when the fanless i7-6500U runs continuously at full load?

The operating temperature ceiling is 50 °C with the SSD installed and 40 °C when the 1 TB HDD is active, so the HDD limit is reached first under sustained heavy workloads.

How much heat and noise does the aluminium passive cooler produce during 24/7 operation?

The fanless aluminium alloy chassis runs completely silent and is designed for 7x24-hour operation within the 0 to 50 °C range, drawing power from a 12 V DC supply.
