Silver 1U rack server front with four 3.5-inch drive bays

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2697 v4 64GB DDR4

SKU CH-24XR-2A625

1U rack server with dual 18-core Xeon CPUs, 64GB DDR4 ECC memory, eight-port MegaRAID controller, four 3.5" hot-swap bays and quad 10GBase-T networking

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores18-Core Processor
  • Dual 18-core Xeon CPUs at 2.3 GHz deliver 36 threads for heavy workloads
  • 64 GB DDR4 2400 MHz registered ECC memory supports data integrity
  • MegaRAID 9361-8i controller enables RAID 0, 1, 5, 6, 10, 50, 60
  • Four 3.5-inch hot-plug drive bays accept SATA or SAS disks
  • Quad 10GBase-T ports plus dedicated IPMI 2.0 LAN for remote management

Dual 18-core Xeon 1U server

The Supermicro SYS-6018U-TR4T+ packs two Intel Xeon E5-2697 v4 processors running at 2.3 GHz with a 3.6 GHz turbo into a single rack unit. Thirty-six total cores and 64 GB of DDR4 2400 MHz registered ECC memory give virtualization hosts and HPC clusters dense multi-threaded throughput.

Four 3.5-inch hot-plug bays with MegaRAID

Four front-accessible trays accept SATA or SAS drives and connect to an LSI MegaRAID 9361-8i controller supporting RAID 0, 1, 5, 6, 10, 50 and 60 with 1 GB cached battery-backed write-back. Quad 10GBase-T ports on an Intel X540 adapter and a dedicated IPMI 2.0 LAN port handle data and out-of-band management without extra cards.

Redundant 750 W platinum supplies sustain load

Dual hot-swap 750 watt platinum-efficiency power modules share the load so the system stays online if one unit fails. The 1U chassis and matched airflow design keep both 18-core CPUs at stable clocks during extended compile, render or database jobs rather than throttling after a short burst.

Besonderheiten

  • Dual 18-core Xeon CPUs at 2.3 GHz deliver 36 threads for heavy workloads
  • 64 GB DDR4 2400 MHz registered ECC memory supports data integrity
  • MegaRAID 9361-8i controller enables RAID 0, 1, 5, 6, 10, 50, 60
  • Four 3.5-inch hot-plug drive bays accept SATA or SAS disks
  • Quad 10GBase-T ports plus dedicated IPMI 2.0 LAN for remote management

Technische Daten

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors InstalledE5-2697 V4
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Fragen zu diesem Artikel

Will the 750 Watt redundant PSUs sustain both 18-core Xeon E5-2697 v4 CPUs at 3.6GHz turbo under continuous load?

Each 750W platinum supply provides redundancy; the dual 18-core processors run at 2.3GHz base with 3.6GHz turbo headroom within the 1U power envelope.

How loud are the 1U fans when the 24 DIMM slots and 4x 3.5" drive bays are fully populated and the server runs 24/7?

High-density 1U cooling moves significant airflow through the front bays and memory area; expect data-center noise levels rather than office quiet.

Which rails or mounting hardware must I already have to install this 1U chassis in a standard 19-inch rack?

The manufacturer highlights state front bezel and rack-mount rails are not included; you need compatible 1U slide or static rails for an 819-series chassis.
