Silver 1U rack server front with four 3.5-inch drive bays

Supermicro

Supermicro SYS-6019U-TN4R4T 1U rack server 2× Xeon Gold 5118 2.3GHz 12-core 64GB DDR4 4× 3.5" bays

SKU CH-J812-RKXRJ

1U rack server with dual 12-core Xeon Gold 5118 CPUs at 2.3 GHz, 64 GB DDR4, MegaRAID 9361-8i controller, four 3.5-inch hot-swap bays, four 10GBase-T ports and dual 750 W PSUs

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores12-Core Processor
  • Dual Xeon Gold 5118 CPUs deliver 24 cores at 2.3GHz base with 3.2GHz turbo
  • 64GB DDR4 2400MHz registered ECC memory ensures data integrity for critical workloads
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1GB cached battery backup
  • Four 10GBase-T ports via Intel X540 provide high-speed network connectivity
  • IPMI 2.0 with dedicated LAN enables remote KVM and virtual media management

Compact 1U dual-Xeon server

The Supermicro SYS-6019U-TN4R4T is a 1U rackmount system with two Intel Xeon Gold 5118 processors running at 2.3 GHz, each offering 12 cores. It ships with 64 GB of DDR4 registered ECC memory and a MegaRAID 9361-8i controller supporting RAID 0, 1, 5, 6, 10, 50 and 60. Four 10GBase-T ports and a dedicated IPMI 2.0 management port handle networking.

Check rack depth and drive stock

Verify that your cabinet can accommodate a 1U chassis with redundant hot-swap power supplies and that the front bezel and rails are sourced separately. The four 3.5-inch hot-plug bays accept SATA or SAS drives but no drives are included, so source compatible media before deployment. Confirm the LGA 3647 socket matches any spare processor plans.

Dual 750 W PSUs power the build

Two platinum-efficiency 750 watt supplies provide redundant power for the CPUs, memory, controller and four 10GBase-T interfaces. The onboard Matrox G200 with 8 MB video memory covers basic console output without occupying a PCIe slot. The IPMI 2.0 port enables remote KVM and virtual media over LAN, freeing the front panel for drive access.

Besonderheiten

  • Dual Xeon Gold 5118 CPUs deliver 24 cores at 2.3GHz base with 3.2GHz turbo
  • 64GB DDR4 2400MHz registered ECC memory ensures data integrity for critical workloads
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1GB cached battery backup
  • Four 10GBase-T ports via Intel X540 provide high-speed network connectivity
  • IPMI 2.0 with dedicated LAN enables remote KVM and virtual media management

Technische Daten

BrandSUPERMICRO
SeriesCSE-819UTS-R751P-T-X11DPU
ModelSYS-6019U-TN4R4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 3647
Number of CPU Cores12-Core Processor
# of Processors InstalledGold 5118
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via AOC-UR-i4XT (Intel X540 10GBase-T)
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Fragen zu diesem Artikel

What comes in the box and what must I purchase separately?

The server includes dual Xeon Gold 5118 processors, 64GB DDR4 ECC memory, MegaRAID 9361-8i controller, four 3.5" hot-swap trays, quad 10GBase-T ports, IPMI 2.0, and dual 750W platinum power supplies. Hard drives and rack rails are not included.

Which memory configuration should I select for this system?

The unit ships with 64GB configured as four 16GB DDR4 2400MHz registered ECC modules. All twelve DIMM slots per processor are available for expansion up to the platform maximum.

What does the 10GBase-T networking actually deliver in daily operation?

Four Intel X540 ports provide line-rate 10GbE over copper RJ45 cabling, enabling high-throughput storage replication, VM migration, and backup traffic without requiring SFP+ transceivers or fibre runs.
