Silver 4U rack server chassis with thirty-six front 3.5-inch drive trays, dual power supplies and a front bezel removed

Supermicro

Supermicro SYS-6048R-E1CR36N 36-bay 4U rack server 2x Xeon E5-2683 v4 512GB DDR4

SKU CH-R8ZN-KAXBJ

36 hot-swap 3.5" drive bays, dual 16-core Xeon E5-2683 v4 at 2.1 GHz, 512 GB DDR4 ECC, MegaRAID 9361-8i, quad 10GBase-T, IPMI 2.0, dual 1280 W platinum PSUs

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores16-Core Processor
  • 32 cores at 2.1 GHz with 3.0 GHz turbo handle heavy workloads
  • 512 GB DDR4 2400 MHz registered ECC memory supports large datasets
  • 36 hot-swap 3.5″ SATA SAS drive bays provide massive storage density
  • MegaRAID 9361-8i controller enables RAID 0 1 5 6 10 50 60
  • Quad 10GBase-T X540 LAN plus IPMI 2.0 dedicated management port

36-bay 4U storage server

The Supermicro SYS-6048R-E1CR36N is a 4U rackmount system built for high-density storage workloads. It ships with dual Intel Xeon E5-2683 v4 16-core processors at 2.1 GHz and 512 GB of DDR4-2400 registered ECC memory. A MegaRAID 9361-8i controller manages up to 36 hot-swap 3.5-inch SATA or SAS drive bays across front and rear. Quad 10GBase-T LAN ports and IPMI 2.0 remote management are standard.

Storage-focused teams needing massive hot-swap

This platform suits organisations that need 36 drive bays in a single 4U chassis with hardware RAID 0, 1, 5, 6, 10, 50 and 60 support. It is not for buyers who require more than eight direct controller ports or who need a larger memory footprint than 512 GB. Teams wanting integrated graphics beyond the basic Matrox G200 should look elsewhere.

Eight-port MegaRAID 9361-8i controller

The installed LSI MegaRAID 9361-8i provides eight internal SAS 12 Gb/s ports with 1 GB cache and battery backup. This port count limits the number of drives that can be attached directly to the hardware RAID engine without additional HBAs or expanders. Verify that eight ports satisfy your backplane topology before purchase.

Besonderheiten

  • 32 cores at 2.1 GHz with 3.0 GHz turbo handle heavy workloads
  • 512 GB DDR4 2400 MHz registered ECC memory supports large datasets
  • 36 hot-swap 3.5″ SATA SAS drive bays provide massive storage density
  • MegaRAID 9361-8i controller enables RAID 0 1 5 6 10 50 60
  • Quad 10GBase-T X540 LAN plus IPMI 2.0 dedicated management port

Technische Daten

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores16-Core Processor
# of Processors InstalledE5-2683 V4
Installed Memory Size512GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Fragen zu diesem Artikel

What does the 2.1 GHz base clock and 16 cores per processor mean for real-world throughput?

Dual Xeon E5-2683 v4 CPUs provide 32 total cores at 2.1 GHz base with 3.0 GHz turbo, suited for virtualization and storage workloads.

How does the MegaRAID 9361-8i controller's 12 Gb/s SAS interface limit drive performance?

The 8-port 12 Gb/s SAS RAID controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache and battery backup.

What physical space and mounting hardware are required for this 4U chassis?

The 4U rackmount server uses a CSE-847BE1C chassis with 36 hot-swap 3.5" drive bays; rack rails and front bezel are not included.
