Silver 4U rack server chassis with 36 front drive bays and dual power supplies

Supermicro

Supermicro SYS-6048R-E1CR36N 36-bay 4U rack server 2x Xeon E5-2690 v4 2.6GHz 14-core 512GB DDR4

SKU CH-8YEN-4BP3Y

4U rack server with 36 hot-swap 3.5″ drive bays, dual Xeon 14-core 2.6 GHz CPUs and 512 GB DDR4 ECC memory

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.60 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual Xeon E5-2690 v4 14-core CPUs deliver 28 total cores for parallel workloads
  • 512GB DDR4 2400MHz ECC memory across 16 DIMMs supports large in-memory datasets
  • MegaRAID 9361-8i 12Gb/s controller with 1GB cache enables RAID 0/1/5/6/10/50/60
  • 36 hot-swap 3.5" SAS/SATA bays provide high-density local storage capacity
  • Quad 10GBase-T Intel X540 ports plus IPMI 2.0 give fast data and remote management

36-bay 4U storage server

The Supermicro SYS-6048R-E1CR36N is a 4U rackmount system built for high-density storage workloads. It ships with dual Intel Xeon E5-2690 v4 processors, each running at 2.6 GHz with 14 cores. The unit includes 512 GB of DDR4 2400 MHz registered ECC memory across 16 modules. It targets organisations that need massive drive capacity in a single chassis.

Twelve-gigabit SAS controller limits

The installed LSI MegaRAID 9361-8i provides eight internal ports running at 12 Gb/s per port. This means the controller can directly address only eight drives without additional expander hardware. The remaining 28 bays rely on the chassis backplane to multiplex connectivity through those eight lanes. RAID levels 0, 1, 5, 6, 10, 50 and 60 are supported, but total throughput is bounded by the eight-port interface.

Dual 1280-watt platinum power supplies

Redundant 1280 W 80 Plus Platinum units supply power to the fully populated chassis. Both modules are hot-swappable and share the load, so a single failure does not interrupt operation. Buyers who need lower power draw or a smaller power budget should verify their actual configuration against the rated output. No rails or front bezel are included.

Besonderheiten

  • Dual Xeon E5-2690 v4 14-core CPUs deliver 28 total cores for parallel workloads
  • 512GB DDR4 2400MHz ECC memory across 16 DIMMs supports large in-memory datasets
  • MegaRAID 9361-8i 12Gb/s controller with 1GB cache enables RAID 0/1/5/6/10/50/60
  • 36 hot-swap 3.5" SAS/SATA bays provide high-density local storage capacity
  • Quad 10GBase-T Intel X540 ports plus IPMI 2.0 give fast data and remote management

Technische Daten

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.60 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2690 V4
Installed Memory Size512GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Fragen zu diesem Artikel

Should I choose the 36-bay model or a smaller bay count for my storage density needs?

This specific model provides exactly 36 hot-swap 3.5" bays — 24 front and 12 rear — so there is no smaller bay-count variant of the SYS-6048R-E1CR36N to select.

What does the 2.6 GHz clock speed deliver once the server is running real workloads?

Dual 14-core Xeon E5-2690 v4 processors run at 2.6 GHz base with 3.5 GHz turbo, giving 28 total cores and 56 threads for parallel throughput in virtualization or database tasks.

How does the 12 Gb/s SAS RAID controller limit drive performance in practice?

The MegaRAID 9361-8i provides eight 12 Gb/s SAS ports with 1 GB cached battery-backed write acceleration, capping each connected drive at 12 Gb/s while supporting RAID 0, 1, 5, 6, 10, 50 and 60.
