Silver 4U rack server chassis with thirty-six front 3.5-inch drive bays

Supermicro

Supermicro SYS-6048R-E1CR36N 4U rack server 36x 3.5" 2x E5-2690 v4 32GB DDR4

SKU CH-0CM1-5K3H3

A 4U rack server holding 36 hot-swap 3.5" drives, dual 14-core Xeon E5-2690 v4 CPUs at 2.6 GHz, 32 GB DDR4, MegaRAID 9361-8i controller, quad 10GBase-T LAN and IPMI 2.0

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.60 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual 14-core Xeon processors at 2.6 GHz deliver high parallel throughput
  • 32 GB DDR4 ECC memory provides error-corrected capacity for critical workloads
  • 36 hot-swap 3.5-inch drive bays enable massive direct-attached storage density
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60 for flexible data protection
  • Quad 10GBase-T ports with X540 controller give high-speed network connectivity

36-bay 4U rack server

The Supermicro SYS-6048R-E1CR36N is a 4U rackmount server designed for high-density storage workloads. It ships with dual Intel Xeon E5-2690 v4 processors, each offering 14 cores at 2.6 GHz, and 32 GB of DDR4 ECC memory. The platform targets enterprises needing massive capacity in a single chassis.

Verify rack depth and power feeds

Confirm your rack can accommodate the 847-series chassis depth and that two 1280 W platinum power supplies can be fed from separate circuits. The system includes 36 hot-swap 3.5-inch trays for SATA or SAS drives but no drives are installed. Front bezel and rack rails are not included.

Sustained throughput with hardware RAID

Under continuous load the LSI MegaRAID 9361-8i controller maintains performance across RAID 0, 1, 5, 6, 10, 50 and 60 using its 1 GB battery-backed cache. Quad 10GBase-T ports from the Intel X540 controller sustain high network throughput while IPMI 2.0 provides remote KVM and virtual media access.

Besonderheiten

  • Dual 14-core Xeon processors at 2.6 GHz deliver high parallel throughput
  • 32 GB DDR4 ECC memory provides error-corrected capacity for critical workloads
  • 36 hot-swap 3.5-inch drive bays enable massive direct-attached storage density
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60 for flexible data protection
  • Quad 10GBase-T ports with X540 controller give high-speed network connectivity

Technische Daten

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.60 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2690 V4
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Fragen zu diesem Artikel

Does the server ship with hard drives, and are rack rails included?

The unit includes 36 hot-swap 3.5-inch SAS/SATA drive trays but no hard drives. Front bezel and rack mount rails are not included and must be purchased separately.

Which processor and memory configuration is installed in this model?

Two Intel Xeon E5-2690 v4 14-core processors running at 2.6 GHz and 32 GB of DDR4 2400 MHz registered ECC memory (4x 8 GB) are pre-installed.

What RAID levels and drive count does the 9361-8i controller support in this chassis?

The MegaRAID 9361-8i provides 8 internal SAS 12 Gb/s ports with 1 GB cache and battery backup, supporting RAID 0, 1, 5, 6, 10, 50 and 60 across the 36 drive bays.
