White all-in-one liquid cooler with 120mm ARGB fan, copper block and 400mm tubes

Thermaltake

Thermaltake TH120 ARGB Snow Edition CL-W346-PL12SW-A liquid cooler

SKU CH-N00B-E8YDV MPN CL-W346-PL12SW-A

All-in-one liquid cooler with a 120 mm radiator, copper water-block and ARGB fan for Intel LGA 1700 and AMD AM5 sockets

  • TypeLiquid Cooling System
  • Block CompatibilityIntel LGA 1700 / 1200 / 1156 / 1155 / 1151 / 1150 AMD AM5 /
  • Block Compatibility - IntelIntel LGA 1700 / 1200 / 1156 / 1155 / 1151 / 1150
  • Block MaterialCopper
  • Radiator Size153.00 x 120.00 x 27.00 mm
  • Radiator MaterialAluminum

Series TH ARGB

Fan Size 1 Fan Slot (120mm)

Color Snow

  • Synchronises with major motherboard RGB ecosystems via 5 V header
  • 1500 RPM fan delivers 59.28 CFM airflow for strong cooling
  • Quiet 28.2 dB-A operation keeps system noise low
  • Copper waterblock base accelerates heat transfer from CPU
  • 400 mm rubber tubing allows flexible routing in compact cases

120 mm all-in-one liquid cooler

The Thermaltake TH120 ARGB Snow Edition is a closed-loop liquid cooler built around a single 120 mm radiator and a 120 mm ARGB fan. It targets builders who want a compact cooling solution for mainstream Intel or AMD sockets without a custom loop. The white Snow finish and addressable lighting suit colour-coordinated builds.

Upgrade path from stock air coolers

This unit replaces basic boxed air coolers when lower noise or tighter clearances are priorities. The jump is worth it if your current cooler hits thermal limits under sustained loads or blocks memory slots. The 1500 RPM fan delivers 59.28 CFM at 28.2 dB-A, offering more headroom than most stock fans.

Clearance and header checklist

Verify that your case can mount a 153 x 120 x 27 mm radiator with a 25 mm fan. Confirm the CPU block clears nearby components; the copper base and pump add height over the socket. Ensure your motherboard has a 5 V 3-pin ARGB header (2510 connector) for sync, or use the included controller. The 400 mm tubes must reach from the CPU socket to the chosen radiator location.

Besonderheiten

  • Synchronises with major motherboard RGB ecosystems via 5 V header
  • 1500 RPM fan delivers 59.28 CFM airflow for strong cooling
  • Quiet 28.2 dB-A operation keeps system noise low
  • Copper waterblock base accelerates heat transfer from CPU
  • 400 mm rubber tubing allows flexible routing in compact cases

Technische Daten

BrandThermaltake
SeriesTH ARGB
ModelCL-W346-PL12SW-A
TypeLiquid Cooling System
Block CompatibilityIntel LGA 1700 / 1200 / 1156 / 1155 / 1151 / 1150
AMD AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2 / FM1
Block Compatibility - IntelIntel LGA 1700 / 1200 / 1156 / 1155 / 1151 / 1150
Block MaterialCopper
Radiator Size153.00 x 120.00 x 27.00 mm
Radiator MaterialAluminum
Fan Size1 Fan Slot (120 mm)
Fan Dim.120.00 x 120.00 x 25.00 mm
Fan RPM1500 R.P.M
Fan Air Flow59.28 CFM
Fan Noise28.2 dB-A
Fan Connector2510 - 3 Pin , 5 V ARGB header - 3 Pin
ColorSnow
LED ColorARGB
Tube Dim.400mm (Length)
Tube MaterialRubber
Features16.8 Million Color LEDs.
Single 120mm RGB Color Radiator Fan.
High Efficiency Radiator.
High Performance Waterblock and Pump.
Synchronizes with ASUS, GIGABYTE, MSI and ASRock.
Package Contents1 x All-in-one Cooler (Radiator + water block + pump)
1 x Accessory Box
1 x Fan
User Manual
Versandgewicht0.75 kg
Paketgröße274 × 218 × 142 mm

Andere Versionen dieses Modells

5 weitere aus dieser Serie

Gleiche Familie, unterschiedlicher Speicher, Kühler oder Takt — vergleichen Sie, bevor Sie sich entscheiden.

Fragen zu diesem Artikel

Will the 153 x 120 x 27 mm radiator and 400 mm tubes fit my case?

The radiator measures 153 by 120 by 27 mm and the tubes are 400 mm long; verify your case supports a 120 mm radiator and that the routing path accommodates the tube length.

Which headers do the 3-pin 2510 fan connector and the 5 V 3-pin ARGB lead plug into?

Attach the fan to a motherboard fan header using its 3-pin 2510 connector and connect the ARGB cable to a 5 V 3-pin addressable RGB header; if the board lacks one, use the included controller.

Do the rubber tubes or the copper cold plate need periodic replacement?

The rubber tubes and copper cold plate are sealed inside the loop and are not user-serviceable; no scheduled replacement is required.
