Black and white 120 mm case fan 25 mm thick with PWM cable

XPG

XPG VENTOPRO120PWM-BKCWW 120 mm PWM case fan 25 mm 75 CFM 10-28 dBA

SKU CH-9434-4752Y MPN VENTOPRO120PWM-BKCWW

A 120 mm PWM case fan with 25 mm thickness, 75 CFM airflow and 10 to 28 dBA noise range

  • Fan Counts1 Fan
  • TypeCase Fan
  • Fan Thickness25mm
  • Bearing Type2 Ball
  • RPMPWM Mode:900 ~ 2150 RPM ± 10% DC Mode:450 ~ 2150 RPM ± 10%
  • Air Flow75 CFM
  • PWM control from 900 to 2150 RPM for precise cooling
  • 75 CFM airflow at a quiet 28 dBA maximum
  • Dual ball bearings built for heavy-duty durability
  • Daisy-chain flat cables simplify multi-fan installation
  • 120 mm frame with 25 mm thickness fits standard mounts

Single 120 mm PWM case fan

The XPG Vento Pro 120 PWM is a single 120 mm case fan designed for system builders who need focused airflow in a standard mounting size. It uses a four‑pin PWM connector so the motherboard can vary speed automatically. The frame is 25 mm thick and comes in a black and white finish.

Dual‑ball bearing and daisy‑chain cable

The fan uses a 2‑ball bearing assembly built for continuous operation under heavy thermal loads. A flat cable with daisy‑chain capability lets several units run from one header, reducing cable clutter inside the chassis. Speed ranges from 450 RPM in DC mode up to 2150 RPM in PWM mode, both with a ±10 % tolerance.

Airflow and noise envelope

Maximum airflow is rated at 75 CFM while the acoustic ceiling sits at 28 dBA; the lower bound is 10 dBA at minimum speed. Builders who need higher static pressure or greater total airflow than a single 120 mm fan can deliver should plan for additional fans or a larger form factor.

Besonderheiten

  • PWM control from 900 to 2150 RPM for precise cooling
  • 75 CFM airflow at a quiet 28 dBA maximum
  • Dual ball bearings built for heavy-duty durability
  • Daisy-chain flat cables simplify multi-fan installation
  • 120 mm frame with 25 mm thickness fits standard mounts

Technische Daten

BrandXPG
SeriesVento
ModelVento Pro 120 PWM
Part NumberVENTOPRO120PWM-BKCWW
Fan Counts1 Fan
TypeCase Fan
Fan Thickness25mm
Bearing Type2 Ball
RPMPWM Mode:900 ~ 2150 RPM ± 10%
DC Mode:450 ~ 2150 RPM ± 10%
Air Flow75 CFM
Noise Level10 - 28dBA (Max)
Power Connector4-Pin PWM
ColorBlack / White
Versandgewicht0.23 kg
Paketgröße152 × 152 × 25 mm

Fragen zu diesem Artikel

Does the 4-pin PWM connector allow the motherboard to control the fan between 900 and 2150 RPM?

Yes, in PWM mode the motherboard can vary speed from 900 to 2150 RPM with ±10 % tolerance; in DC mode the range extends down to 450 RPM.

Will the 25 mm thickness and 120 mm frame fit a standard case fan mount?

The fan uses the common 120 mm square frame and 25 mm thickness, matching typical case, radiator and heatsink mounting holes.

How do I connect multiple fans using the daisy-chain feature without losing PWM control?

Plug the first fan into the motherboard PWM header, then link each additional fan to the previous one using the flat daisy-chain cable; all fans share the same PWM signal.
