Rectangular black metal rackmount UPS with touchscreen LCD panel and front battery access

MINUTEMAN

MINUTEMAN ED5KRT-5KTF UPS 5000VA 4275W 208-240V Rack/Tower

SKU CH-NF7J-E2722 MPN ED5KRT-5KTF

Online double-conversion UPS delivers 5000 VA and 4275 W with selectable 208-240 V output, hot-swappable batteries and a touchscreen LCD panel

  • International Version208 (Default), 220, 230, 240VAC
  • Input Voltage Range156-280VAC
  • Input Frequency40 to 70Hz at Full Load
  • Input ConnectionHardwire w/optional NEMA L6-30P (6-ft.)
  • VA Rating5000VA
  • Watts4275W

Model ED5KRT-5KTF

Näytä 16 muuta kokoonpanoa

Yliviivatut versiot ovat olemassa, mutta niitä ei ole varastossa täällä.

  • 5000 VA capacity supports demanding server loads
  • 4275 watt output delivers consistent power to critical equipment
  • Online double-conversion topology isolates devices from utility irregularities
  • Hot-swappable battery modules enable replacement without downtime
  • Touchscreen LCD panel simplifies configuration and real-time monitoring

5000VA Online UPS for Rack or Tower Deployment

The Minuteman Endeavor ED5KRT-5KTF is a 5000VA, 4275W online double-conversion UPS designed for 208-240V environments. It supports critical servers, network gear and storage arrays that require continuous, conditioned power with zero transfer time. The unit fits a 4U rack space or stands as a tower for flexible installation.

11 Minutes at Half Load, 3 Minutes at Full Load

At 50 percent load the internal batteries deliver approximately 11 minutes of runtime, dropping to 3 minutes at full 4275W load. This window covers graceful shutdowns or bridges short utility interruptions. Extended outages require additional battery packs; the UPS cannot sustain heavy loads beyond the rated minutes without external expansion.

Hot-Swappable Batteries and Touchscreen LCD

Front-access BM0097 battery modules can be replaced without powering down connected equipment, maintaining uptime during maintenance. A multi-colour touchscreen LCD provides real-time status, configuration and predictive replacement alerts. RS-232 and USB ports enable software integration for automated shutdown and monitoring, while 3140-joule surge protection guards attached devices.

Kohokohdat

  • 5000 VA capacity supports demanding server loads
  • 4275 watt output delivers consistent power to critical equipment
  • Online double-conversion topology isolates devices from utility irregularities
  • Hot-swappable battery modules enable replacement without downtime
  • Touchscreen LCD panel simplifies configuration and real-time monitoring

Tekniset tiedot

BrandMINUTEMAN
SeriesENDEAVOR
ModelED5KRT-5KTF
International Version208 (Default), 220, 230, 240VAC
Input Voltage Range156-280VAC
Input Frequency40 to 70Hz at Full Load
Input ConnectionHardwire w/optional NEMA L6-30P (6-ft.)
VA Rating5000VA
Watts4275W
Output Voltage208 (Default), 220, 230, 240VAC
Output Frequency50/60Hz, auto selecting, +/-3Hz (unless synchronized to utility)
Outlets5
Outlet Type(2) L6-30R / (2) L6-20R / (1) 3-wire Terminal Block (208-240VAC)
(4) 5-15/20R / (2) L5-30R / (1) 3-wire Terminal Block (120VAC)
Battery Run TimeHalf Load: 11 min
Full Load: 3 min
Battery ReplaceableBM0097
Interface PortRS-232, USB
ApprovalscUL, CE, UL1778, FCC Class B, Energy Star 2.0, RoHS2
Surge Energy Rating3140 Joules
TemperatureOperating Temperature: +32° to +104°F (0° to +40°C)
Storage Temperature: +5° to +131°F (-15° to +55°C)
Humidity0 to 95%, non-condensing
Dimensions10.22" x 17.24" x 23.82"
Weight243.54 lbs.
Lähetyspaino110.45 kg
Pakkauksen mitat605 × 437 × 259 mm

Tämän mallin muut versiot

5 lisää samasta mallistosta

Sama tuoteperhe, eri muisti, jäähdytin tai kellotaajuus — vertaile ennen päätöstä.

Kysymyksiä tästä tuotteesta

Will the ED5KRT-5KTF accept the 208 V feed from my existing PDU without rewiring?

Yes, the input voltage range is 156-280 VAC, so a 208 V source falls well inside the window and requires no rewiring.

How can I confirm the UPS is regulating voltage correctly after installation?

The multi-colour touchscreen LCD shows real-time input and output voltage, frequency and load percentage, letting you verify regulation at a glance.

Which cables and battery modules come in the box, and what must I order separately?

The unit ships with the internal BM0097 battery set installed; the NEMA L6-30P input cord and any output cables for the L6-30R, L6-20R, 5-15/20R or terminal-block outlets are sold separately.
