ABS ALI560 gaming PC i7-11700F RTX 3060 Ti 16GB 1TB NVMe
Refurbished mid-tower desktop with an 8-core i7-11700F, RTX 3060 Ti 8 GB, 16 GB DDR4 and 1 TB NVMe
- TypeGaming & Entertainment
- Form FactorMid Tower
- UsageConsumer / Gaming
- ProcessorIntel Core i7-11700F 2.50 GHz (4.90 GHz Turbo)
- Processor Main Features64 bit 8-Core 16-Thread Processor
- Cache Per Processor16 MB L3 Cache
- 8-core 16-thread i7-11700F powers multitasking and high frame rates
- RTX 3060 Ti 8 GB GDDR6 drives 1440p gaming with ray-tracing support
- 16 GB DDR4 3000 MHz memory keeps heavy workloads responsive
- 1 TB NVMe SSD loads games and apps in seconds
- 650 W 80 Plus Gold PSU and four 120 mm RGB fans deliver stable, cool operation
Refurbished mid-tower gaming desktop
This ABS Master ALI560 system arrives as a refurbished unit with an Intel Core i7-11700F processor, NVIDIA GeForce RTX 3060 Ti graphics card, 16 GB of DDR4 memory and a 1 TB M.2 NVMe SSD. It ships with Windows 10 Home and is Windows 11 ready. The configuration targets 1080p and 1440p gaming for buyers who accept a refurbished condition.
Installation and common issues
The PC is fully assembled so installation means connecting power, display and peripherals then completing Windows setup. Graphics driver updates may be required for the RTX 3060 Ti. The 650 W 80 Plus Gold power supply uses standard ATX cables; verify the GPU power connectors match the card supplied because the brand may vary.
Pre-order compatibility checks
Confirm your monitor has a DisplayPort or HDMI input compatible with the RTX 3060 Ti outputs. Ensure desk space suits a mid-tower chassis with tempered glass side and front panels. The motherboard uses an Intel B560 chipset with DDR4 slots; memory upgrades must be DDR4 modules. The 1 TB M.2 NVMe drive occupies one M.2 slot; check the board layout if you plan additional M.2 storage.
Points forts
- 8-core 16-thread i7-11700F powers multitasking and high frame rates
- RTX 3060 Ti 8 GB GDDR6 drives 1440p gaming with ray-tracing support
- 16 GB DDR4 3000 MHz memory keeps heavy workloads responsive
- 1 TB NVMe SSD loads games and apps in seconds
- 650 W 80 Plus Gold PSU and four 120 mm RGB fans deliver stable, cool operation
Caractéristiques
| Brand | ABS |
|---|---|
| Series | Master |
| Model | ALI560 |
| Type | Gaming & Entertainment |
| Form Factor | Mid Tower |
| Usage | Consumer / Gaming |
| Processor | Intel Core i7-11700F 2.50 GHz (4.90 GHz Turbo) |
| Processor Main Features | 64 bit 8-Core 16-Thread Processor |
| Cache Per Processor | 16 MB L3 Cache |
| Memory | 16 GB DDR4 3000 MHz (2 x 8 GB) |
| Storage | 1 TB M.2 NVMe SSD |
| Graphics | NVIDIA GeForce RTX 3060 Ti 8 GB (Brand May Vary) |
| Power Supply | 650W 80 Plus Gold (Brand May Vary) |
| Case | DEEPCOOL MATREXX 50 ADD-RGB 4F Mid-Tower Case 4x120mm ADD-RGB Fans, Full-size Tempered Glass Side And Front Panel |
| Cooling System | CPU Cooler: RGB CPU Cooler Case Fan: 4 x 120 mm RGB fans |
| Operating System | Windows 10 Home 64-bit 👉Check ABS systems with Windows 11 👉Check gaming pc with Windows 11 Pro |
| Windows 11 | Ready |
| Chipset | Intel B560 |
| CPU Type | Intel Core i7 11th Gen |
| CPU Name | Intel Core i7-11700F |
| L3 Cache Per CPU | 16 MB |
| CPU Main Features | 64 bit 8-Core 16-Thread Processor |
| GPU/VGA Type | GeForce RTX 3060 Ti |
| GPU Memory | 8 GB GDDR6 |
| Virtual Reality Ready | Yes |
| Memory Capacity | 16GB DDR4 |
| Memory Speed | DDR4 3000 |
| Memory Spec | 8 GB x 2 |
| Memory Slot (Total) | 4 |
| Memory Slot (Available) | 2 |
| SSD | 1TB NVMe |
| HDD | No |
| Optical Drive Type | No |
| LAN Chipset | Intel I219-V 1Gb Ethernet |
| LAN Speed | 10/100/1000Mbps |
| WLAN | WiFi 802.11a/b/g/n/ac |
| WiFi Generation | Wi-Fi 5 |
| Front USB | 2 x USB 2.0 1 x USB 3.0 |
| Front Audio Ports | 1 x Microphone 1 x Headphone |
| PS/2 | 1 x PS/2 Keyboard/Mouse combo port |
| Video Ports | 1 x HDMI 2.0b 3 x DisplayPort 1.4 |
| Rear USB | 1 x USB 3.2 Gen 2 Type-A 1 x USB 3.2 Gen 2 Type-C 4 x USB 2.0 Type-A |
| RJ45 | 1 port |
| Rear Audio Ports | 3 ports |
| PCIe Slots | 1 x PCIe 4.0 x16 + 1 x PCIe 3.0 x16 (max. x4) Intel 11th & 10th Gen Processors 1 x PCIe 4.0/3.0 x16 slot(s)* - Intel 11th Gen processors support PCIe 4.0 x16 - Intel 10th Gen processors support PCIe 3.0 x16 Intel B560 Chipset 1 x PCIe 3.0 x16 slot (supports x4 mode)* 1 x PCIe 3.0 x1 slots * Enable RST PCIe Storage Remapping for PCH attached PCIe slots to activate Intel Optane Memory. |
| Dimensions (H x W x D) | 18.90" x 8.27" x 17.32" |
| Poids d’expédition | 16.35 kg |
| Dimensions du colis | 622 × 584 × 375 mm |
Questions sur cet article
How can I confirm the Intel Core i7-11700F is hitting its 4.90 GHz turbo under load?
Open Task Manager or HWMonitor while gaming and watch the CPU frequency column; sustained readings at or near 4.90 GHz across the 8 cores show the processor is boosting as designed.
Which components come pre-installed and which must I source myself for the ALI560?
The system ships with the i7-11700F, RTX 3060 Ti 8 GB, 16 GB DDR4 3000 MHz (2×8 GB), 1 TB M.2 NVMe SSD, 650 W 80 Plus Gold PSU, DEEPCOOL MATREXX 50 case with four 120 mm RGB fans, RGB CPU cooler, and Windows 10 Home. Only peripherals such as monitor, keyboard and mouse are needed separately.
Should I choose the 16 GB DDR4 3000 MHz configuration or look for a higher-capacity kit?
The board uses a B560 chipset with two occupied DIMM slots; 16 GB (2×8 GB) at 3000 MHz is the factory spec. If you need more capacity later, you would replace the existing kit rather than add to it.
