Full-height PCIe graphics card with DMS-59 connector and passive heatsink

AMD

AMD ATI FirePro 2270 512MB GDDR3 DMS-59 workstation graphics card

SKU CH-XMB2-GX9SJ

Entry workstation GPU with 512 MB GDDR3, DMS-59 output and PCIe 2.0 x16 interface

  • Memory TypeGDDR5
  • Drives two displays from one DMS-59 connector
  • 512 MB GDDR3 memory handles professional 2D workloads
  • PCIe 2.0 x16 interface fits standard workstation slots
  • Supports OpenGL and DirectX 10.1 for CAD compatibility
  • 600 MHz GPU clock delivers stable viewport performance

Professional graphics card

The AMD ATI FirePro 2270 is a new workstation graphics card with 512 MB of GDDR3 memory on a 64-bit bus. It uses a PCI Express 2.0 x16 interface and a single DMS-59 port that can drive two displays. The GPU is based on the ATI Radeon HD 4550 core running at 600 MHz and supports DirectX 10.1 and OpenGL.

System compatibility check

Verify your motherboard has a free PCI Express x16 slot that accepts PCIe 2.0 cards. Ensure the power supply can deliver enough current for a low-profile card and that your chassis has space for the bracket. The DMS-59 connector requires a splitter cable for dual DVI or VGA monitors, which is not included with the card.

Suited for legacy workstations

This card suits IT teams maintaining older Dell Precision or OptiPlex systems that need a direct replacement for the JCPR7 part. It is not for users who require modern API support, higher resolutions than 2560x1600 digital, or more than 512 MB of video memory for current CAD or 3D applications.

Points forts

  • Drives two displays from one DMS-59 connector
  • 512 MB GDDR3 memory handles professional 2D workloads
  • PCIe 2.0 x16 interface fits standard workstation slots
  • Supports OpenGL and DirectX 10.1 for CAD compatibility
  • 600 MHz GPU clock delivers stable viewport performance

Caractéristiques

Memory TypeGDDR5

Questions sur cet article

Does the DMS-59 port come with a splitter cable for two monitors, or must I buy it separately?

The card ships with a DMS-59 connector; a DMS-59 to dual DVI or VGA splitter cable is not included and must be purchased separately.

The listing shows both GDDR3 and GDDR5 memory types — which one does this JCPR7 model actually use?

The detailed specifications confirm 512 MB of GDDR3 memory running at 600 MHz on a 64-bit bus.

What does the 600 MHz GPU clock mean for 3D viewport performance in OpenGL 3.1 or DirectX 10.1 applications?

The 600 MHz core and memory clocks drive the Radeon HD 4550 engine, delivering entry-level workstation 3D performance suitable for 2D CAD and basic 3D modelling at up to 2560x1600 digital resolution.
