Compact silver metal box with screw terminals and label

Analog Technologies

Analog Technologies AHV12V6KV1MAW High Voltage Power Supply 6kV 1mA 24V

SKU CH-ZS8K-SSJZ3

Delivers 0 to 6 kV at 1 mA from a 24 V input with 0 to 5 V control and shutdown pin

  • TypeHigh Voltage Power Supply

Options 12V to 6000V 1mA

  • AHV24VN6KV1MAW
  • AHV24V6KV1MAW
  • AHV24V5KV2MAW
  • 24V to -5000V 1mA
  • 24V to 5000V 1mA
  • 12V to -6000V 1mA
  • 12V to 6000V 3mA
  • 12V to 6000V 1mA

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Adjustable 0–6 kV output for versatile high-voltage applications
  • 24 V DC input with 130–710 mA draw fits standard industrial supplies
  • 0–5 V control voltage enables precise linear regulation
  • Electronic shutdown pin allows remote on/off switching
  • Monitor output 0–1.5 V gives real-time voltage feedback

Compact 6 kV High-Voltage Module

This compact DC-DC converter accepts a 24 V input and delivers an adjustable 0 to 6 kV output at up to 1 mA. A 0 to 5 V control voltage sets the output across the full span, while a dedicated shutdown pin enables remote on/off switching. The module includes a 5 V reference and a 0 to 1.5 V monitor voltage for system integration. It is built for laboratory and industrial equipment requiring a stable, regulated high-voltage source.

Suited for Precision High-Voltage Applications

Engineers designing X-ray systems, spectral analysers, electrospinning rigs or capacitor-charging circuits will appreciate the linear regulation and low ripple. The 1 mA current limit makes it unsuitable for high-power deposition or particle-accelerator loads that demand sustained current beyond this level. Buyers needing more than 6 kV or higher output current should evaluate alternative modules.

Critical Spec: 1 mA Maximum Output Current

The 1 mA ceiling is the single parameter that determines whether this supply can drive your load. Verify that your application’s peak and continuous current draw stay within this limit before purchase.

Points forts

  • Adjustable 0–6 kV output for versatile high-voltage applications
  • 24 V DC input with 130–710 mA draw fits standard industrial supplies
  • 0–5 V control voltage enables precise linear regulation
  • Electronic shutdown pin allows remote on/off switching
  • Monitor output 0–1.5 V gives real-time voltage feedback

Caractéristiques

TypeHigh Voltage Power Supply

Questions sur cet article

What input voltage and current range does the module require from the 24V supply?

The unit operates from 24V ± 1V DC and draws between 130mA and 710mA depending on load.

How is the output voltage set and what control signal is used for shutdown?

Output voltage 0–6kV is set by a 0–5V control voltage on the CTRL pin; a separate electronic shutdown pin enables remote on/off switching.

What ongoing checks or replacements are needed for the high-voltage output section?

Monitor the 0–1.5V monitor voltage to verify output stability; the 5V ± 0.05V reference should remain within tolerance for precise regulation.
