Rectangular ATX power supply unit with matte black finish and 135 mm fan grille visible on one side

ASUS

ASUS AP-750G 750 W power supply

SKU CH-QHX5-Z6ZZ1 MPN AP-750G

Fully modular 750 W ATX 3.0 power supply with 80 Plus Gold efficiency, a 135 mm dual-ball-bearing fan, PCIe Gen 5 16-pin connector and comprehensive protection circuits

  • TypeATX12V
  • Maximum Power750 W
  • Fans1 x 135 mm
  • Max PSU Length150 mm
  • ModularFull Modular
  • Energy-Efficient80 PLUS GOLD Certified

Options 750W

  • Delivers 750 W for high-performance builds
  • 80 Plus Gold efficiency reduces wasted energy
  • Fully modular cables keep the case tidy
  • ATX 3.0 compliant with PCIe Gen 5 16-pin connector
  • 135 mm axial-tech fan with dual ball bearings runs cooler

ATX 3.0 power supply for modern builds

The ASUS AP-750G delivers 750 W through a fully modular ATX12V design that meets ATX 3.0 guidelines. A single 135 mm fan with dual ball bearings and axial-tech blades provides cooling. 80 PLUS Gold certification reflects low-ESR capacitors and premium components. The unit measures 150 x 150 x 86 mm and weighs 1.466 kg.

Suitable for PCIe Gen 5 graphics cards

One native 16-pin PCIe connector plus three 8-pin PCIe connectors support current and next-generation GPUs. Two CPU 4+4-pin cables handle high-end desktop processors. Five SATA and three peripheral connectors cover storage and accessories. Builders needing more than three 8-pin PCIe cables or a shorter depth than 150 mm should verify case clearance first.

Check case depth and cable routing before ordering

The 150 mm length must fit your chassis with room for the 24-pin, CPU and PCIe cables, which range from 610 mm to 675 mm. Confirm your motherboard uses a 24-pin main connector and 8-pin CPU power. Ensure the 100-240 V input matches your mains supply. The package includes all listed cables and a power cord.

Points forts

  • Delivers 750 W for high-performance builds
  • 80 Plus Gold efficiency reduces wasted energy
  • Fully modular cables keep the case tidy
  • ATX 3.0 compliant with PCIe Gen 5 16-pin connector
  • 135 mm axial-tech fan with dual ball bearings runs cooler

Caractéristiques

BrandASUS
ModelAP-750G
TypeATX12V
Maximum Power750 W
Fans1 x 135 mm
Max PSU Length150 mm
ModularFull Modular
Energy-Efficient80 PLUS GOLD Certified
ProtectionOPP/OVP/UVP/SCP/OCP/OTP
Input Voltage100 - 240 V
Output+3.3V@20A, +5V@20A, +12V@62A, [email protected] , [email protected]
ConnectorsMB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 16-pin x 1 (both PSU & connector side)
PCI-E 8-pin x 3
SATA x 5
PERIPHERAL x 3
Dimensions150 x 150 x 86 mm
Weight1.466 kg (single PSU)
Package ContentPower Cord x 1
Motherboard Power Cable x 1 (610mm)
CPU Cable x 2 (650mm)
PCI-E Gen 5 16-pin Cable x 1 (675mm)
PCI-E (16-pin to 8-pin-8-pin) Cable x1 (675mm)
PCI-E 1-to-1 Cable x 1 (675mm)
SATA 1-to-2 Cable x 1 (400+120mm)
SATA 1-to-3 Cable x 1 (400+120+120mm)
Peripheral 1-to-3 Cable x 1 (400+150+150mm)
User Manual x 1
Poids d’expédition2.95 kg
Dimensions du colis356 × 203 × 152 mm

Autres versions de ce modèle

1 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Do I need a case that fits a 150 mm deep ATX power supply?

The unit is 150 mm deep and 86 mm tall, so the case must accept a standard ATX PSU of at least that length and height.

Can I keep my older motherboard with a 24-pin ATX and two 4+4-pin CPU sockets?

The PSU includes one 24/20-pin motherboard cable and two 4+4-pin CPU cables, so it connects directly to those sockets.

How do I confirm the PSU is delivering power to a PCIe Gen 5 graphics card after installation?

The bundled 16-pin PCIe Gen 5 cable plugs into the PSU’s 16-pin port and the card’s 16-pin connector; the system will post and the GPU will appear in device manager when power is correct.
