ASUS ATS V2 GeForce RTX 5070 graphics card with dual-fan cooler and metal backplate

ASUS

ASUS ATS V2 GeForce RTX 5070 12GB graphics card

SKU CH-7RGV-BWSEX

A 12 GB GDDR7 graphics card with 6144 CUDA cores, PCI Express 5.0 x16, HDMI 2.1b and DisplayPort 2.1b for 7680 x 4320 resolution

  • InterfacePCI Express 5.0 x16
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5070
  • ArchitectureBlackwell
  • CUDA Cores6144

model ATS V2

  • 12 GB GDDR7 memory at 28 Gbps feeds the 6144 CUDA cores for high frame rates
  • PCI Express 5.0 x16 link removes bandwidth bottlenecks in modern platforms
  • 2 HDMI 2.1b and 3 DisplayPort 2.1b ports drive four 7680 x 4320 displays
  • DLSS 4.0 with Blackwell architecture upscales lower resolutions to sharp 4K output
  • DirectX 12 Ultimate and OpenGL 4.6 support enable latest rendering features

ASUS ATS V2 GeForce RTX 5070 12GB

The ASUS ATS V2 GeForce RTX 5070 is a graphics card built on the Blackwell architecture with 12GB of GDDR7 memory. It connects through a PCI Express 5.0 x16 interface and delivers 6144 CUDA cores for compute and gaming workloads.

12GB GDDR7 for 1440p and 4K gaming

This card suits players targeting high refresh rates at 1440p or entry-level 4K with DLSS 4.0 support. Buyers who need more than 12GB of video memory for heavy creative workloads or multi-monitor surround setups should look at something else.

192-bit memory interface at 28 Gbps

The 192-bit bus combined with a 28 Gbps effective memory clock determines the memory bandwidth available to the GPU. If your workload is limited by memory throughput rather than raw compute, this specification is the deciding factor.

Points forts

  • 12 GB GDDR7 memory at 28 Gbps feeds the 6144 CUDA cores for high frame rates
  • PCI Express 5.0 x16 link removes bandwidth bottlenecks in modern platforms
  • 2 HDMI 2.1b and 3 DisplayPort 2.1b ports drive four 7680 x 4320 displays
  • DLSS 4.0 with Blackwell architecture upscales lower resolutions to sharp 4K output
  • DirectX 12 Ultimate and OpenGL 4.6 support enable latest rendering features

Caractéristiques

BrandASUS
SeriesATS
ModelATS-RTX5070-12G-V2
InterfacePCI Express 5.0 x16
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5070
ArchitectureBlackwell
CUDA Cores6144
Effective Memory Clock28 Gbps
Memory Size12GB
Memory Interface192-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI2 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
CoolerTriple Fans
Recommended PSU Wattage750W
Power Connector1 x 16-Pin
HDCP ReadyYes
Form FactorATX
Max GPU Length329 mm
Card Dimensions (L x H)12.95 x 5.51 x 2.46 inch
Slot Width3.125 Slot
Package Contents1 x Speedsetup Manual
1 x TUF Graphics Card Holder
1 x TUF Velcro Hook & Loop
1 x TUF Magnet
1 x TUF Gaming Certificate
1 x Thank You Card
1 x Adpater Cable (1 to 2)

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How much clearance does the ASUS ATS V2 GeForce RTX 5070 12GB need for its PCI Express 5.0 x16 slot?

The card occupies a standard PCI Express 5.0 x16 slot and requires a case with enough length and height for a dual-slot design; check your chassis specifications for maximum graphics card length and available bracket space.

What is the correct order for connecting the 2 x HDMI 2.1b and 3 x DisplayPort 2.1b outputs during installation?

Install the card into the PCI Express 5.0 x16 slot, secure the bracket screw, then attach the required PCIe power cables before connecting any of the five display outputs to your monitors.

When should the thermal paste on the GeForce RTX 5070 GPU be replaced?

Thermal paste on the GPU die typically lasts several years; plan to replace it only if temperatures rise noticeably under load or when disassembling the cooler for cleaning or repair.
