Black 96% wireless gaming keyboard with OLED screen and knob, magnetic switches, metal top frame, PBT keycaps

ASUS

ASUS ROG Azoth 96 HE 90MP040H-BKAA20 gaming keyboard

SKU CH-XKWV-GQY7X MPN 90MP040H-BKAA20

A 96% wireless gaming keyboard with hot-swappable magnetic switches offering adjustable 0.1–3.5 mm actuation, 8000 Hz polling rate, OLED touchscreen, and six-layer dampening for a refined typing feel

  • NameROG Azoth
  • Keyboard InterfaceUSB + 2.4GHz + Bluetooth
  • Design StyleStandard
  • Layout96%
  • Palm RestNo
  • Mechanical KeyboardYes
  • Customisable actuation from 0.1–3.5 mm with 0.01 mm precision tuning
  • Hall-effect sensor cuts electrical noise for accurate input detection
  • Tri-mode connectivity with up to 8000 Hz polling in wired and wireless
  • Full-colour OLED touchscreen and three-way knob for instant settings control
  • Six-layer dampening with four PORON® layers, IXPE and silicone for cushioned feel

Compact 96% Wireless Keyboard

The ASUS ROG Azoth 96 HE is a tri-mode gaming keyboard built around hot-swappable ROG HFX V2 magnetic switches and a next-gen ROG Hall sensor. It connects via USB, 2.4GHz wireless or Bluetooth to Windows 10, Windows 11 and macOS. Per-key RGB lighting and a full-colour OLED touchscreen with a three-way knob provide system info and on-the-fly settings control.

Upgrade From Fixed-Actuation Boards

This keyboard replaces mechanical decks that lock you into a single actuation point. The magnetic switches let you tune actuation anywhere between 0.1mm and 3.5mm in 0.01mm steps, so rapid-trigger needs and deliberate typing coexist on the same board. The jump is worth it when you want analog-style control without buying a second specialist keyboard.

Hot-Swap Install With Magnetic Care

Switches pull out with the included tool and press in without soldering, while keycaps lift off via the supplied puller. The six-layer gasket mount uses four PORON layers, an IXPE pad and a silicone pad that can be swapped to adjust firmness. Take care aligning the Hall-sensor switches during swaps; debris in the sensor gap can cause chatter until cleared.

Points forts

  • Customisable actuation from 0.1–3.5 mm with 0.01 mm precision tuning
  • Hall-effect sensor cuts electrical noise for accurate input detection
  • Tri-mode connectivity with up to 8000 Hz polling in wired and wireless
  • Full-colour OLED touchscreen and three-way knob for instant settings control
  • Six-layer dampening with four PORON® layers, IXPE and silicone for cushioned feel

Caractéristiques

BrandASUS
NameROG Azoth
ModelM901 ROG AZOTH 96 HE/BLK/HFXV2/CA/PBT
Part Number90MP040H-BKAA20
Keyboard InterfaceUSB + 2.4GHz + Bluetooth
Design StyleStandard
Layout96%
Palm RestNo
Mechanical KeyboardYes
Key SwitchROG HFX V2 Magnetic Switch
Key Switch TypeMagnetic
Keyboard ColorBlack
BacklitPer-Key RGB LEDs
Dimensions382 x 136 x 42mm
TypeMagnetic
Mouse IncludedNo
Operating System SupportedWIN11 / WIN10 / macOS
FeaturesHot-swappable ROG HFX V2 magnetic switches: Refined keystrokes with customizable 0.1–3.5mm actuation and 0.01mm-step precise tuning
ROG Hall sensor: Exceptional precision, accurate input detection, reduces electrical noise and interference, and increases magnetic flux tolerance for superior performance
Superb connectivity: ROG SpeedNova 8K wireless technology, wired USB, and Bluetooth® connectivity support up to five devices simultaneously; wired and wireless modes offer up to 8K polling rate
Full-color OLED touchscreen: Three-way knob allows instant switching between and adjustment
Package Contents1 x ROG Azoth 96 HE
1 x Wrist rest
1 x USB Type-C® to Type-C® Cable
1 x USB Type-C® to Type-A adapter
1 x USB dongle extender
1 x ROG Keycap puller
1 x ROG Switch puller
3 x ROG-themed keycaps
1 x Ctrl Keycap
1 x Warranty booklet
1 x Quick Start Guide
1 x ROG Sticker
1 x ROG thank you card
Poids d’expédition2.68 kg
Dimensions du colis432 × 178 × 83 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What desk space does the 382 x 136 mm footprint of this 96% keyboard need?

The board measures 382 mm wide by 136 mm deep and stands 42 mm tall, so allow at least that rectangle plus room for the detachable wrist rest and cable routing.

How do I swap the ROG HFX V2 magnetic switches and what step is often missed?

Pull the keycap with the included puller, then use the switch puller to lift the switch straight up; the step many miss is re-calibrating the 0.1–3.5 mm actuation point in software after inserting the new switch.

Which parts of the six-layer dampening stack will wear and need replacement?

The four PORON® foam layers, IXPE pad and silicone pad absorb vibration over time; they are not user-replaceable parts, so the keyboard relies on the hot-swappable switches and doubleshot PBT keycaps for long-term serviceability.
