Silver four-bay desktop NAS with front drive trays and status LEDs

ASUSTOR

ASUSTOR AS6804T 4-bay NAS 16 GB DDR5 Ryzen V3C14 2.3 GHz

SKU CH-R6GD-Z9V0J MPN AS6804T

Four-bay desktop NAS with quad-core Ryzen V3C14 at 2.3 GHz, 16 GB DDR5 ECC RAM, four M.2 slots, two 10GbE ports, two 5GbE ports, and dual USB4 at 40 Gbps

  • TypeDesktop NAS
  • Ports2 x 10GbE
  • Port RJ-452 x 2.5 GbE
  • Port USB2x USB4+3x USB 3.2 Gen 2 Type-A
  • HDD Interface4 x SATA (4 x Bay)
  • Form Factor4Bay SATA HDD + 4*M.2 SSD
  • Quad-core Ryzen V3C14 reaches 3.8 GHz turbo for responsive multi-user workloads
  • 16 GB DDR5 ECC memory protects data integrity during intensive operations
  • Four M.2 slots with PCIe 4.0 enable high-speed NVMe caching or storage tiers
  • Dual 10GbE plus dual 5GbE ports deliver flexible multi-gigabit network connectivity
  • Two USB4 ports at 40 Gbps and three USB 3.2 Gen 2 ports simplify external expansion

Four-bay desktop NAS with AMD Ryzen V3C14

The ASUSTOR AS6804T is a four-bay desktop NAS built around a quad-core AMD Ryzen V3C14 processor running at 2.3 GHz with a 3.8 GHz turbo frequency. It ships with 16 GB of DDR5 ECC memory installed and supports expansion up to 64 GB across two slots. The unit runs ADM 5.0 and accommodates four SATA drives plus four M.2 NVMe SSDs for a mixed storage pool.

96 TB maximum raw capacity across eight drive slots

The chassis accepts four 3.5-inch SATA hard drives and four M.2 NVMe SSDs, yielding a combined raw ceiling of 96 TB. RAID 0, 1, 5, 6, 10 and JBOD are supported so buyers can choose redundancy or performance. This capacity limit is the single figure that determines whether the AS6804T fits a given dataset or backup target.

Tool-less drive trays and front-access M.2 slots

Drive bays use tool-less trays for quick SATA installation while the four M.2 slots sit behind a removable front cover for NVMe upgrades. Common issues include forgetting to enable the M.2 slots in ADM before expecting them to appear and mixing SATA drives of very different ages which can degrade rebuild performance.

Points forts

  • Quad-core Ryzen V3C14 reaches 3.8 GHz turbo for responsive multi-user workloads
  • 16 GB DDR5 ECC memory protects data integrity during intensive operations
  • Four M.2 slots with PCIe 4.0 enable high-speed NVMe caching or storage tiers
  • Dual 10GbE plus dual 5GbE ports deliver flexible multi-gigabit network connectivity
  • Two USB4 ports at 40 Gbps and three USB 3.2 Gen 2 ports simplify external expansion

Caractéristiques

BrandAsustor
SeriesLockerStor Gen3
ModelAS6804T
TypeDesktop NAS
Ports2 x 10GbE
Port RJ-452 x 2.5 GbE
Port USB2x USB4+3x USB 3.2 Gen 2 Type-A
HDD Interface4 x SATA (4 x Bay)
Form Factor4Bay SATA HDD + 4*M.2 SSD
Operating SystemADM 5.0
ProcessorAMD Ryzen
Installed Memory16GB
Max Memory Capacity64GB
Memory Slot2
Included HDD CapacityN/A
Max Capacity96TB
RAIDRAID 0, 1, 5, 6, 10, and JBOD
Environment Remote ControlHDD, cooling fan, CPU temperature, network status
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Power Consumption68.68W
Temperature0°C - 40 °C
Humidity5-95% R.H
UsageBackup & stream media through personal cloud
Dimensions12.7 x 11.8 x 9.4
Weight10.74
Sports Team4 Piece
Poids d’expédition4.63 kg
Dimensions du colis318 × 295 × 241 mm

Questions sur cet article

How does the 2.3 GHz Ryzen V3C14 perform when the NAS is serving files and running containers simultaneously?

The quad-core processor boosts to 3.8 GHz under load, so file transfers and Docker containers share the same CPU without a dedicated GPU bottleneck.

What real-world throughput can I expect from the 10GbE ports when connected to a 10GbE switch and fast SSD storage?

Each 10GbE port caps at 10 Gbps; with dual ports you can aggregate or separate workloads, but the ceiling remains 10 Gbps per link.

What drive heights and M.2 lengths fit in the four bays and four M.2 slots?

The four SATA bays accept standard 3.5-inch or 2.5-inch drives, while the four M.2 slots support 2280 NVMe modules.
