Small black square mini PC, compact barebone form factor, matte finish

Beelink

Beelink SER5 Ryzen 5 5500U 16GB 480GB barebone mini PC

SKU CH-5HT3-5E3ZM

Compact desktop with Ryzen 5 5500U, 16GB DDR4, 480GB NVME, triple 4K output, Wi-Fi 6, Bluetooth 5.4 and 2.5G LAN

  • ColorBlack
  • CPU TypeAMD Ryzen 5 5500U
  • CPU SocketFP6
  • Memory installed16GB
  • Memory slot2 SO-DIMM
  • Memory Type SupportedDDR4

Group SER5/5500U/16G/480G

  • 6-core Ryzen 5 5500U up to 4.0 GHz handles multitasking smoothly
  • 16 GB dual-channel DDR4 ready for 64 GB upgrades
  • 480 GB NVME SSD with M.2 slot supporting 4 TB expansion
  • Triple 4K 60 Hz output via HDMI, DP and USB-C
  • Wifi 6, Bluetooth 5.4 and 2.5 Gbps LAN for fast connectivity

Compact Ryzen 5 5500U barebone

The Beelink SER5 is a new mini-PC barebone built around an AMD Ryzen 5 5500U six-core processor with integrated Radeon 7-core graphics. It ships with 16 GB of DDR4 memory in dual-channel configuration and a 480 GB NVME SSD, while Windows 11 Pro comes pre-installed. The 19 V 3.42 A adapter powers the unit.

Suits multi-display office work.

This system suits users who need triple 4K 60 Hz output via HDMI, DP and USB-C for productivity or light gaming on integrated graphics. Buyers who require a dedicated graphics card, more than two SO-DIMM slots or a 2.5-inch drive bay populated out of the box should look elsewhere.

Single M.2 2280 NVME slot caps internal SSD

The board provides one M.2 2280 NVME slot supporting PCIe 3.0 speeds, limiting internal solid-state upgrades to a single drive of up to 4 TB. Memory can reach 64 GB across the two DDR4 slots, but storage density hinges entirely on that lone NVME connector.

Points forts

  • 6-core Ryzen 5 5500U up to 4.0 GHz handles multitasking smoothly
  • 16 GB dual-channel DDR4 ready for 64 GB upgrades
  • 480 GB NVME SSD with M.2 slot supporting 4 TB expansion
  • Triple 4K 60 Hz output via HDMI, DP and USB-C
  • Wifi 6, Bluetooth 5.4 and 2.5 Gbps LAN for fast connectivity

Caractéristiques

BrandBeelink
SeriesSER 5
ColorBlack
CPU TypeAMD Ryzen 5 5500U
CPU SocketFP6
Memory installed16GB
Memory slot2 SO-DIMM
Memory Type SupportedDDR4
Max Memory Supported64GB
Dual Channel Memory SupportedYes
PCIPCIE3.0
Storage Installed480GB
M.2 Slot1x M.2
Integrated GraphicsAMD Radeon Graphics 7core 1800MHz
LANRJ45 2.5G
Max LAN Speed2.5Gbps
Wireless LANMT7920
WiFi GenerationWi-Fi 6
BluetoothBluetooth 5.4
Front USB2
Front Audio Ports1 jacks
Other Front Ports1 Type-C
HDMI1
DisplayPort1 x DisplayPort
Rear USB2
RJ451
Input100-240V AC,50/60Hz
Power Supply19V/3.42A

Autres versions de ce modèle

2 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install the 2.5-inch SATA drive and which screw do I use?

Open the bottom cover, slide the drive into the internal SATA bay, and secure it with the single screw already present on the chassis.

When will the 480 GB M.2 NVMe SSD need replacement?

The PCIe 3.0 NVMe drive has no moving parts; plan to replace it only if SMART health drops below threshold or you need more than 480 GB.

At what temperature does the Ryzen 5 5500U throttle during long loads?

The processor begins thermal throttling at 100 °C junction temperature, which the stock cooler manages under typical sustained workloads.
