Compact barebone mini PC in matte black plastic chassis with silver accents, front ports and VESA mount visible

BRENUC

BRENUC BREC Mini PC Core Ultra 9 285H 128GB DDR5 Arc 140T barebone

SKU CH-R1YG-A8XGG

Barebone mini PC with 14-core Intel Core Ultra 9 285H, dual-channel DDR5-5600 support up to 128 GB, Intel Arc 140T graphics driving four 4K displays, Wi-Fi 6E and Bluetooth 5.3

  • AI FeaturesAI Ready
  • CPU TypeIntel Core Ultra 9 285H
  • CPU Cores14
  • Memory installedNo Memory
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR5 5600

Option Barebone

  • 14-core Core Ultra 9 285H with AI acceleration handles heavy workloads
  • Supports 128 GB DDR5 5600 dual-channel memory for large datasets
  • Intel Arc 140T graphics drives four 4K 60 Hz displays
  • Wi-Fi 6E and Bluetooth 5.3 give fast, stable wireless links
  • 5 Gb Ethernet plus four USB 3.2 Gen2 ports for wired speed

Compact AI Workstation

The BRENUC BREC is a new barebone mini PC built around the Intel Core Ultra 9 285H processor with 14 cores and integrated Arc 140T graphics. It accepts up to 128 GB of DDR5 5600 memory across two 288-pin DIMM slots running in dual-channel mode. The chassis provides 2.5 Gbps Ethernet, Wi-Fi 6E, Bluetooth 5.3 and a 120 W power adapter.

Target Users and Limits

This system suits developers, analysts and signage operators who need strong CPU compute, AI acceleration and four 4K 60 Hz outputs in a small footprint. It is not for buyers who require discrete GPU performance, additional PCIe expansion slots or legacy COM and parallel ports. The barebone format also means RAM and storage must be sourced separately.

Deciding Specification

The maximum supported memory of 128 GB DDR5 5600 is the single figure that determines whether this platform fits the workload. Projects that need larger capacity or faster memory speeds will require a different class of hardware.

Points forts

  • 14-core Core Ultra 9 285H with AI acceleration handles heavy workloads
  • Supports 128 GB DDR5 5600 dual-channel memory for large datasets
  • Intel Arc 140T graphics drives four 4K 60 Hz displays
  • Wi-Fi 6E and Bluetooth 5.3 give fast, stable wireless links
  • 5 Gb Ethernet plus four USB 3.2 Gen2 ports for wired speed

Caractéristiques

BrandBRENUC
SeriesBREC
ModelIntel Core UItra 9 285H
AI FeaturesAI Ready
CPU TypeIntel Core Ultra 9 285H
CPU Cores14
Memory installedNo Memory
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported128GB
Dual Channel Memory SupportedYes
Serial ATA1 x M.2 B-key PCIe Gen3 x1 22x42(SAT3.0)
M.2 Slot1 x M.2 2280 PCIe 4.0 X4 NVMe SSD
Discrete Graphic CardIntel ARC 140T Graphics
Onboard AudioIntegrated
Channel7.1 Channel
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.3
Front USB2 x USB 3.2 Gen2(10Gbps) Type-A ports
Front Audio Ports3.5mm Audio Jack
Other Front Ports1 x Type-C (USB2.0)
HDMI2 x HDMI 2.1 TMDS
Thunderbolt2 x Type-C Full Function Port
Rear USB2 x USB 3.2 Gen2(10Gbps) Type-A port
RJ451 x 2.5Gb RJ45
Input19VDC /6.32A
Power Supply120W
Dimensions136 x 123 x 51mm
MaterialHigh-density plastic with metal frame
PackagingIndividual retail box packaging

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What DDR5 modules and how many fit the BREC Mini PC?

The board has two 288-pin DDR5 5600 SODIMM slots supporting up to 128 GB total in dual-channel mode.

Which screw secures the M.2 2280 NVMe drive during installation?

A single M.2 mounting screw (not included) fastens the 2280 drive; the B-key 22x42 slot uses its own separate screw.

When should the 120 W 19 V power adapter be replaced?

Replace the adapter if the barrel jack becomes loose, the cable frays, or the unit no longer powers on reliably.
