Compact square mini PC in dark grey plastic with metal frame, front ports visible

BRENUC

BRENUC BREC Mini PC Intel Core Ultra 9 285H 64GB DDR5 2TB SSD

SKU CH-W2SH-04Z2F

Compact AI-ready mini PC with Intel Core Ultra 9 285H, 64GB DDR5, 2TB SSD, Arc 140T graphics, WiFi 6E and 2.5Gbps LAN

  • AI FeaturesAI Ready
  • CPU TypeIntel Core Ultra 9 285H
  • CPU Cores14
  • Memory installedNo Memory
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR5 5600

Option 64GB RAM / 2TB SSD

  • 14-core Intel Core Ultra 9 285H reaches 5.4 GHz for heavy multitasking
  • 64 GB DDR5 5600 dual-channel memory handles large workloads fast
  • Intel Arc 140T graphics drives four 4K 60 Hz displays simultaneously
  • Wi-Fi 6E plus Bluetooth 5.3 gives low-latency wireless connectivity
  • 5 Gbps LAN and 10 Gbps USB 3.2 Gen2 ports move data quickly

Intel Core Ultra 9 285H Mini PC

The BRENUC BREC is a compact barebone system built around the Intel Core Ultra 9 285H processor with 14 cores and a 5.4 GHz maximum turbo frequency. It ships with 64 GB of DDR5 5600 memory and a 2 TB NVMe SSD installed. Integrated Intel Arc 140T graphics drive up to four 4K 60 Hz displays via two HDMI 2.1 and two USB-C ports. The chassis includes a 120 W power adapter and a VESA mount.

Suited to AI workloads and multi-display stations

This unit targets developers and professionals who need on-device AI acceleration, high memory bandwidth, and quadruple 4K output in a small footprint. The 2.5 GbE port and Wi-Fi 6E plus Bluetooth 5.3 cover modern connectivity needs. Buyers who require discrete GPU performance, additional internal 2.5-inch drive bays, or legacy serial and parallel ports should consider other form factors.

Sustained load behaviour in a compact chassis

The 120 W adapter and high-density plastic frame with an internal hardware structure manage thermal output during extended multi-core workloads. Dual-channel DDR5 5600 maintains memory throughput for long rendering or inference sessions. Four simultaneous 4K 60 Hz streams stress the Arc 140T graphics continuously, so airflow around the VESA-mounted unit remains important for consistent clock speeds.

Points forts

  • 14-core Intel Core Ultra 9 285H reaches 5.4 GHz for heavy multitasking
  • 64 GB DDR5 5600 dual-channel memory handles large workloads fast
  • Intel Arc 140T graphics drives four 4K 60 Hz displays simultaneously
  • Wi-Fi 6E plus Bluetooth 5.3 gives low-latency wireless connectivity
  • 5 Gbps LAN and 10 Gbps USB 3.2 Gen2 ports move data quickly

Caractéristiques

BrandBRENUC
SeriesBREC
ModelIntel Core UItra 9 285H
AI FeaturesAI Ready
CPU TypeIntel Core Ultra 9 285H
CPU Cores14
Memory installedNo Memory
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported128GB
Dual Channel Memory SupportedYes
Serial ATA1 x M.2 B-key PCIe Gen3 x1 22x42(SAT3.0)
M.2 Slot1 x M.2 2280 PCIe 4.0 X4 NVMe SSD
Discrete Graphic CardIntel ARC 140T Graphics
Onboard AudioIntegrated
Channel7.1 Channel
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.3
Front USB2 x USB 3.2 Gen2(10Gbps) Type-A ports
Front Audio Ports3.5mm Audio Jack
Other Front Ports1 x Type-C (USB2.0)
HDMI2 x HDMI 2.1 TMDS
Thunderbolt2 x Type-C Full Function Port
Rear USB2 x USB 3.2 Gen2(10Gbps) Type-A port
RJ451 x 2.5Gb RJ45
Input19VDC /6.32A
Power Supply120W
Dimensions136 x 123 x 51mm
MaterialHigh-density plastic with metal frame
PackagingIndividual retail box packaging

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Do I need to buy DDR5 5600 SODIMMs separately because the unit ships with no memory installed?

Yes, the system arrives with zero memory so you must supply two DDR5 5600 SODIMMs up to 128 GB total for dual-channel operation.

Will my existing 2.5 Gbps network switch and Wi-Fi 6E router work with the 2.5G RJ45 and AX211 wireless?

The 2.5G RJ45 port and Intel AX211 Wi-Fi 6E adapter are backward compatible with your current switch and router.

How can I verify the Arc 140T graphics are driving all four video outputs at 4K 60 Hz?

Open Intel Graphics Command Center and confirm each HDMI and Type-C port reports an active 4K 60 Hz signal.
