Small silver square mini PC with front USB ports and audio jack

BRENUC

BRENUC i5-13500H barebone mini PC 16GB DDR5 512GB NVME

SKU CH-WYBR-3MA53 MPN i5-13500H

A compact 136 x 123 x 55 mm barebone with an Intel Core i5-13500H up to 4.7 GHz, 16 GB DDR5 5200, 512 GB NVME, Intel Iris Xe graphics, 2.5 Gbps LAN, Wi-Fi 6 and Bluetooth 5.2

  • CPU TypeIntel Core i5-13500H
  • Memory installed16GB
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR5 5200
  • Max Memory Supported96GB
  • Dual Channel Memory SupportedYes

Group 32G RAM / 1T SSD

  • Compact 136x123x55mm footprint fits tight spaces
  • Intel Core i5-13500H up to 4.7GHz handles heavy multitasking
  • 16GB DDR5 5200MHz dual-channel memory scales to 96GB
  • 512GB NVME PCIe 4.0 storage delivers fast data access
  • Intel Iris Xe graphics drives four displays via HDMI and Type-C

Compact barebone for small spaces

The BRENUC i5-13500H barebone mini PC measures 136x123x55mm, making it suited for desks or VESA mounts where space is limited. It arrives with an Intel Core i5-13500H processor, 16GB of DDR5 5200 memory and a 512GB NVME drive already installed. This configuration targets office workers, home users and digital-signage deployments that need a quiet, low-footprint system ready to run immediately.

Build integration and expansion

Two 288-pin DIMM slots support dual-channel DDR5 up to 96GB, so additional memory can be added without replacing the factory modules. The PCIe 4.0 NVME slot is occupied, but the 2.5Gbps Intel i226V LAN port, Wi-Fi 6 and Bluetooth 5.2 handle wired and wireless networking without extra cards. Front-facing USB 3.2 Gen2 Type-A and Type-C ports plus a 3.5mm audio jack keep peripherals accessible, while HDMI and Type-C video outputs drive up to four displays from the integrated Intel Iris Xe graphics.

Capacity and headroom

The included 16GB of DDR5 and 512GB NVME cover typical productivity workloads, web browsing and multi-monitor streaming without bottlenecks. Memory headroom extends to 96GB for heavier virtualization or content-creation tasks, though the integrated graphics share system RAM and lack dedicated video memory. Users needing discrete GPU performance, additional internal storage bays or more than four simultaneous displays will find those requirements beyond what this platform provides.

Points forts

  • Compact 136x123x55mm footprint fits tight spaces
  • Intel Core i5-13500H up to 4.7GHz handles heavy multitasking
  • 16GB DDR5 5200MHz dual-channel memory scales to 96GB
  • 512GB NVME PCIe 4.0 storage delivers fast data access
  • Intel Iris Xe graphics drives four displays via HDMI and Type-C

Caractéristiques

BrandBRENUC
SeriesBREB
Modeli5-13500H
CPU TypeIntel Core i5-13500H
Memory installed16GB
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR5 5200
Max Memory Supported96GB
Dual Channel Memory SupportedYes
Storage Installed512GB
Discrete Graphic CardIntel Iris Xe Graphics
Onboard AudioIntegrated
Channel7.1 Channel
LANIntel i226V
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6
BluetoothBluetooth 5.2
Front USB2 x USB 3.2Gen2 (10Gbps ) Type-A
1 x USB 3.2 Gen2 (10Gbps ) Type-C
Front Audio Ports3.5mm Audio Jack
HDMI2 x HDMI 2.0
Rear USB1 x Type-C
1 x USB 3.2 Gen2(10Gbps) Type-A
1 x USB 2.0 Type-A
RJ451 x 2.5Gb RJ45
Input19V/6.32A
Power Supply120W
Dimensions136mm*123mm*55mm
PackagingIndividual retail box packaging

Autres versions de ce modèle

2 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What thermal limit appears first when the Core i5-13500H runs at 4.7 GHz for long periods?

The compact 136x123x55 mm chassis relies on its integrated cooler, so sustained turbo clocks are capped by the thermal solution before the CPU hits its own throttle point.

How loud and hot does the unit get when the Intel i226V 2.5 Gbps LAN and WiFi 6 run all day?

With only the built-in fan moving air through the 55 mm height, surface temperatures rise and fan speed increases noticeably under continuous network and compute load.

Which display cables must I already own to use the quad-screen capability?

You need four cables matching the video outputs on the rear panel — typically HDMI and Type-C — because the barebone ships without any display adapters.
