COUGAR
COUGAR POLAR X2 1200W power supply
ATX 3.0 1200 W fully modular supply with 12VHPWR for PCIe 5.0, 80 Plus Platinum 92% efficiency, 135 mm hydro-dynamic fan, Japanese capacitors, zero-noise mode, 180 mm length
- TypeATX 3.0 Compatible
- Maximum Power1200 W
- Fans1 x 135 mm
- Main Connector20+4Pin
- PCI-Express Connector7 x 6+2-Pin
- SATA Power Connector12
Options ATX3.0 80+ Platinum(1200W)
- ATX3.0 80+Platinum(1050W)
- ATX3.0 80+ Platinum(1200W)
- 1200 W output powers demanding multi-GPU builds
- 12VHPWR connector handles 200 % power excursion for PCIe 5.0 cards
- 92 % typical efficiency at 80 PLUS Platinum cuts running costs
- Fully modular design with 12 SATA connectors keeps cable clutter low
- Hydro dynamic bearing fan and zero-noise mode deliver Cybenetics A- quiet operation
1200 W ATX 3.0 PSU for PCIe 5.0 builds
This 1200 W ATX 3.0 power supply targets builders running current multi-core platforms and PCIe 5.0 graphics cards. It delivers 1200 W at 50 °C ambient temperature using 100 % Japanese capacitors and a 135 mm hydro-dynamic bearing fan. Full modularity and a Cybenetics A- noise rating keep cable clutter low and acoustics controlled.
Suits high-end single-GPU rigs.
The unit includes a native 12VHPWR connector rated for 200 % power excursion and seven 6+2-pin PCIe connectors, covering one flagship GPU with headroom. Twelve SATA connectors support ample storage. Builders planning multiple high-wattage GPUs or extreme overclocking beyond 1200 W should look at higher-capacity units instead.
Check case depth and cable routing space
The PSU measures 180 mm long, 150 mm wide and 86 mm tall; verify your chassis clears that length and has room for the fully modular cable bundle. Ensure the motherboard accepts a 20+4-pin main connector and that the 12VHPWR cable reaches your graphics card without sharp bends. An ATX 3.0-ready motherboard is recommended for full feature support.
Points forts
- 1200 W output powers demanding multi-GPU builds
- 12VHPWR connector handles 200 % power excursion for PCIe 5.0 cards
- 92 % typical efficiency at 80 PLUS Platinum cuts running costs
- Fully modular design with 12 SATA connectors keeps cable clutter low
- Hydro dynamic bearing fan and zero-noise mode deliver Cybenetics A- quiet operation
Caractéristiques
| Brand | COUGAR |
|---|---|
| Series | POLAR X2 |
| Type | ATX 3.0 Compatible |
| Maximum Power | 1200 W |
| Fans | 1 x 135 mm |
| Main Connector | 20+4Pin |
| PCI-Express Connector | 7 x 6+2-Pin |
| SATA Power Connector | 12 |
| Max PSU Length | 180 mm |
| Modular | Full Modular |
| Energy-Efficient | 80 PLUS PLATINUM Certified |
| PSU Noise Level | Cybenetics A- |
| Dimensions | 180 x 150 x 86 (mm) |
Autres versions de ce modèle
1 de plus dans cette gamme
Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.
Questions sur cet article
Does the PSU include the 12VHPWR cable for a PCIe 5.0 graphics card?
Yes, the unit ships with a native 12+4-pin 12VHPWR cable rated for 200% power excursion.
Will my existing 6+2-pin PCIe cables work with this supply?
The PSU provides seven 6+2-pin PCIe outputs, so older graphics cards connect directly without adapters.
How can I confirm the Zero Noise Mode is active after installation?
At low load the 135 mm hydro-dynamic bearing fan stops completely; you will hear no fan noise until the internal temperature rises.
