DELL ne_r6625_vi_vp_sb_os PowerEdge R6625 rack server 2×EPYC 9124 16-core 32GB DDR5 480GB SSD
A 1U rack server with dual 16-core EPYC 9124 CPUs, 32GB DDR5 and a 480GB SSD for HPC and dense virtualization
- WorkloadHPC, Dense VDI and Virtualization
- TypeRack
- Rack Height1U
- SecurityAMD Secure Encrypted Virtualization (SEV) AMD Secure Memory
- CPU TypeAMD EPYC 9004 Series
- CPU Speed9124 (3.00 GHz)
- Dual EPYC 9124 CPUs deliver 32 cores at 3.00 GHz
- 32 GB DDR5 memory scales to 6 TB across 24 slots
- 480 GB SATA SSD provides fast boot and OS storage
- 1U rack design fits eight 2.5" universal drive bays
- Built-in security with SEV, SME, signed firmware and TPM 2.0
Dual 16-core EPYC server for dense virtualisation
The PowerEdge R6625 fits two AMD EPYC 9124 processors, each with 16 cores at 3.00 GHz and 64 MB cache, into a 1U rack chassis. Thirty-two gigabytes of DDR5 memory ship in two 16 GB modules across 24 slots. A single 480 GB SATA SSD handles boot duties while eight universal 2.5-inch bays accept SAS, SATA or NVME drives for capacity.
Sustained multi-threaded throughput in a 1U form
Dual processors and 32 threads per socket keep compute density high for HPC and VDI workloads that run continuously. The 1400 W power supply feeds both CPUs and the full complement of drive bays without throttling under prolonged load. Memory bandwidth scales with DDR5 across all populated channels as additional modules are added.
Security-focused chassis with flexible drive layout
AMD Secure Encrypted Virtualisation, Secure Memory Encryption and a silicon root of trust protect data at rest and in use. Cryptographically signed firmware and secure boot harden the boot chain. The eight universal drive slots let operators mix interface types per workload, while three single-wide GPU slots support accelerator cards for specialised tasks. Windows Server 2022 Standard is pre-installed.
Points forts
- Dual EPYC 9124 CPUs deliver 32 cores at 3.00 GHz
- 32 GB DDR5 memory scales to 6 TB across 24 slots
- 480 GB SATA SSD provides fast boot and OS storage
- 1U rack design fits eight 2.5" universal drive bays
- Built-in security with SEV, SME, signed firmware and TPM 2.0
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge R6625 |
| Model | ne_r6625_vi_vp_sb_os |
| Workload | HPC, Dense VDI and Virtualization |
| Type | Rack |
| Rack Height | 1U |
| Security | AMD Secure Encrypted Virtualization (SEV) AMD Secure Memory Encryption (SME) Cryptographically signed firmware Data at Rest Encryption (SEDs with local or external key mgmt) Secure Boot Secured Component Verification (Hardware integrity check) Secure Erase Silicon Root of Trust System Lockdown (requires iDRAC9 Enterprise or Datacenter) TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| CPU Type | AMD EPYC 9004 Series |
| CPU Speed | 9124 (3.00 GHz) |
| Number of CPU Cores | 16-Core Processor |
| Cache Memory | 64MB Cache |
| CPU Features | 16-core, 32-thread |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 32GB (2 x 16GB) |
| Memory Type | DDR5 |
| Max Memory Capacity | 6TB |
| Number of Memory Slots | 24 |
| Hard Drive (Installed) | None |
| SSD (Installed) | 480GB |
| Servers_Graphic Installed | 0 |
| GPU Type | Supports 3 x Single-Wide GPUs |
| Expansion Slots | Slot 1: 1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length or 1 x16 Gen5 Full height, Half length Slot 2: 1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length or 1 x16 Gen5 Full height, Half length Slot 3: 1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length |
| Expansion Bays | Front: - Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 80 TB - Up to 10 x 2.5-inchSAS/SATA/NVMe (HDD/SSD) max 153.6 TB - Up to 16 x E3.S NVMe direct drives max 122.88 TB Rear: - Up to 2 x 2.5-inch SAS/SATA (HDD/SSD) max 30.72 TB - Up to 2 x E3.S NVMe direct drives max 15.36.8 TB |
| Operating System | Windows Server 2022 Standard |
| Power Characteristics | Single 1400W |
| Dimensions | 1.69" x 18.97" x 32.4" |
| Poids d’expédition | 22.68 kg |
| Dimensions du colis | 762 × 635 × 254 mm |
Questions sur cet article
How much power does the single 1400W supply draw when both EPYC 9124 CPUs run at full load all day?
The system ships with a single 1400W power supply rated to support both 16-core EPYC 9124 processors and the 480GB SSD under sustained workloads.
Which DDR5 modules must I already own to expand the 32GB installed memory toward the 6TB maximum?
The server has 24 DDR5 slots; two are filled with 16GB modules, so any additional DDR5 RDIMMs you install must match the platform's supported speeds and capacities.
Can the 2.5-inch chassis accept my existing SAS and SATA drives alongside the 480GB SSD?
Yes, the 1U chassis provides eight universal drive bays that support SAS, SATA and NVMe devices, so older 2.5-inch SAS or SATA drives can be installed in the remaining slots.
