DELL PowerEdge R630 10SFF 1x Xeon E5-2697 v4 384GB DDR4 No Drive
A 1U rack server with ten 2.5‑inch drive bays, one 18‑core Xeon at 2.3 GHz and 384 GB DDR4 ECC memory, no drives installed
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.3GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size384GB
- 18-core Xeon E5-2697 v4 at 2.3GHz handles heavy workloads
- 384GB DDR4 ECC memory supports large virtualisation clusters
- 10 SFF bays with PERC H730 RAID controller enable flexible storage
- Dual 10GbE and 1GbE ports provide high-throughput networking
- iDRAC8 Enterprise licence allows full remote server management
PowerEdge R630 10-bay server
The Dell PowerEdge R630 is a 1U rack server built for virtualization, database and high-performance compute workloads. It ships with a single Intel Xeon E5-2697 v4 processor running at 2.3 GHz with 18 cores and 45 MB cache. The chassis supports up to ten 2.5-inch SAS drives and a second processor for future expansion.
384 GB DDR4 and PERC H730 RAID
The system includes 384 GB of DDR4 ECC registered memory, leaving headroom toward the 1.5 TB maximum across 24 DIMM slots. A Dell PERC H730 SAS RAID controller is installed, providing hardware RAID for the drive bays. Integrated graphics handle console output while iDRAC8 Enterprise enables full remote management.
Verify rack depth and power before ordering
The unit measures 36 by 24 by 10 inches and weighs 40 pounds, so confirm your rack depth and weight capacity. Two 495 W power supplies are fitted; check that your PDU connectors and circuit capacity match. No drives or rail kit are included unless requested separately.
Points forts
- 18-core Xeon E5-2697 v4 at 2.3GHz handles heavy workloads
- 384GB DDR4 ECC memory supports large virtualisation clusters
- 10 SFF bays with PERC H730 RAID controller enable flexible storage
- Dual 10GbE and 1GbE ports provide high-throughput networking
- iDRAC8 Enterprise licence allows full remote server management
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.3GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 384GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 3,60 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SAS |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
Can the 384GB DDR4 be expanded later without replacing the existing modules?
The board supports up to 1.5TB total, so the installed 384GB can be supplemented with additional DDR4 ECC registered DIMMs rather than swapped out.
Will the single Xeon E5-2697 v4 with its 18 cores become the bottleneck before the PERC H730 RAID controller saturates?
With 18 cores at 2.3GHz and 45MB cache, the processor typically reaches full utilisation before the H730 hits its SAS throughput ceiling under heavy database or virtualisation loads.
How loud and hot does the 1U chassis get when both 495W supplies run 24/7 with ten 2.5-inch drives spinning?
Dual 495W supplies and ten drive bays mean sustained airflow through the 1U rack enclosure; fan speed ramps under load, so expect noticeable noise and warm exhaust in a closed rack.
