DELL
DELL PowerEdge R630 10SFF 2x Xeon E5-2699 v3 512GB DDR4
Ten-bay 2.5-inch rack server with dual 2.3GHz Xeon E5-2699 v3 processors, 512GB DDR4 ECC memory and PERC H730 SAS controller
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.3GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size512GB
- Dual 18-core Xeon 2699 v3 CPUs deliver 36 threads at 2.3 GHz
- 512 GB DDR4 ECC memory installed with room to reach 1.5 TB
- 10 front 2.5-inch drive bays backed by PERC H730 SAS controller
- iDRAC8 Enterprise remote management for full out-of-band control
- Dual 495 W power supplies and quad-port 10 GbE / 1 GbE networking included
Dual 18-core Xeon density
The Dell PowerEdge R630 packs two Xeon E5-2699 v3 processors at 2.3GHz with eighteen cores each and 45MB cache per chip. That yields thirty-six cores and seventy-two threads in a single 1U rack unit. It is built for virtualisation hosts, database clusters and compute-heavy workloads that demand maximum core count per rack slot.
Replaces older dual-socket nodes
Moving from earlier dual-socket servers with lower core counts or smaller memory ceilings, this platform delivers a substantial leap in parallel throughput and memory capacity. The jump is worth it when licensing costs scale per socket and you need to consolidate more virtual machines or larger in-memory datasets onto fewer physical hosts.
Fits dense 2.5-inch storage arrays
Ten front-accessible 2.5-inch bays connect through the PERC H730 SAS controller for flexible RAID layouts. Dual 495W supplies and iDRAC8 Enterprise remote management come standard. The chassis accepts up to 1.5TB of DDR4 ECC registered memory, leaving room to grow beyond the installed 512GB without changing platforms.
Points forts
- Dual 18-core Xeon 2699 v3 CPUs deliver 36 threads at 2.3 GHz
- 512 GB DDR4 ECC memory installed with room to reach 1.5 TB
- 10 front 2.5-inch drive bays backed by PERC H730 SAS controller
- iDRAC8 Enterprise remote management for full out-of-band control
- Dual 495 W power supplies and quad-port 10 GbE / 1 GbE networking included
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.3GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 512GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 5,00 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
What rack depth and height does the 36 x 24 x 10 in chassis require?
The server is 36 inches deep, 24 inches wide and 10 inches high, so a standard rack with at least 36-inch depth and 10-inch vertical space is needed.
How are the two Xeon E5-2699 v3 processors and 512GB DDR4 memory installed, and what step is often missed?
Both processors are already seated in the two sockets and the 512GB DDR4 ECC registered modules populate the DIMM slots; the step often missed is ensuring the memory configuration matches the per-channel population rules for optimal performance.
When will the PERC H730 SAS controller or the 495W power supplies need replacement?
The PERC H730 RAID controller and the two 495W power supplies are installed and tested; plan to evaluate the controller battery and power-supply fans after several years of continuous operation.
