DELL
DELL PowerEdge R630 8SFF 1x Xeon E5-2699 v3 384GB DDR4 No Drive
A 1U rack server with an 18-core 2.3 GHz Xeon, 384 GB DDR4, PERC H730 controller and eight 2.5-inch bays
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.3GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size384GB
- 18-core Xeon E5-2699 v3 handles heavy workloads
- 384 GB DDR4 ECC memory supports large datasets
- 8 SFF bays with PERC H730 RAID controller enable flexible storage
- iDRAC8 Enterprise provides full remote server management
- Dual 495 W power supplies deliver redundant power
PowerEdge R630 8-bay rack server
The Dell PowerEdge R630 fits eight 2.5-inch drive bays in a 1U rack-mount chassis. One Intel Xeon E5-2699 v3 running at 2.3 GHz delivers 18 cores and 45 MB of cache. The system ships with 384 GB of DDR4 ECC registered memory installed.
Upgrade from smaller R630 configs
This configuration replaces an R630 with fewer cores, less memory or fewer drive bays. The jump is worth it when workloads need the full 18-core processor, the 384 GB memory capacity or the eight-bay chassis for dense local storage.
Check rack depth and power budget
Verify that your rack can accommodate the 36-inch depth and that the dual 495 W power supplies match your PDU connectors. Confirm the PERC H730 SAS controller supports the RAID level you plan to run with SATA drives. Ensure iDRAC8 Enterprise licensing meets your remote-management requirements.
Points forts
- 18-core Xeon E5-2699 v3 handles heavy workloads
- 384 GB DDR4 ECC memory supports large datasets
- 8 SFF bays with PERC H730 RAID controller enable flexible storage
- iDRAC8 Enterprise provides full remote server management
- Dual 495 W power supplies deliver redundant power
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.3GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 384GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 3,84 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
What rack depth and width clearances does the 36 x 24 x 10 inch chassis require?
The unit is 36 inches deep, 24 inches wide and 10 inches high; allow extra depth for cable management and front-door clearance in a standard four-post rack.
Which rails or mounting hardware are needed to install the R630 in a four-post rack?
A compatible Dell sliding rail kit for 12th-generation PowerEdge servers is required; it is available on request and must be secured to both front and rear rack posts.
When will the two 495 W power supplies or the PERC H730 controller battery need replacement?
Replace power supplies if a fault LED lights or redundancy is lost; the RAID controller cache battery typically lasts three to five years and should be swapped when iDRAC reports a degraded state.
