DELL
DELL PowerEdge R630 8SFF 2x Xeon E5-2690 v4 384GB DDR4 No Drive
A 1U rack server with dual 14-core Xeon processors at 2.6GHz, 384GB DDR4 ECC memory, PERC H730 RAID controller, and eight 2.5-inch drive bays ready for storage configuration
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.6GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size384GB
- Dual 14-core Xeon 2.6GHz CPUs deliver high compute density
- 384GB DDR4 ECC memory supports large virtualisation workloads
- Eight 2.5-inch drive bays with PERC H730 RAID controller enable flexible storage
- iDRAC8 Enterprise licence provides full remote management out of band
- Dual 495W power supplies and quad-port 10GbE/1GbE networking ensure uptime
Dual-socket Xeon server for dense compute
The Dell PowerEdge R630 packs two E5-2690 v4 processors, each with 14 cores at 2.6 GHz, into a 1U rack chassis. The system ships with 384 GB of DDR4 ECC registered memory and a PERC H730 SAS controller, leaving the eight 2.5-inch drive bays empty for custom storage layouts. Remote management is handled by iDRAC8 Enterprise.
Dual 495 W supplies and efficient airflow
Redundant 495 watt power supplies feed both CPUs and the memory array while the front-to-rear cooling path keeps thermals steady under sustained load. Fan curves are tuned for data-centre aisles, so acoustic output is higher than office gear but consistent during 24/7 operation.
Eight-bay 2.5-inch chassis with flexible I/O
The 8SFF front panel accepts SAS or SATA drives and the H730 controller supports RAID 0, 1, 5, 6, 10, 50 and 60. Rear I/O includes dual 10 GbE and dual 1 GbE ports from Intel I350/X540 adapters. Rail kit is available separately; buyers needing GPU acceleration or more than eight drives should choose a larger platform.
Points forts
- Dual 14-core Xeon 2.6GHz CPUs deliver high compute density
- 384GB DDR4 ECC memory supports large virtualisation workloads
- Eight 2.5-inch drive bays with PERC H730 RAID controller enable flexible storage
- iDRAC8 Enterprise licence provides full remote management out of band
- Dual 495W power supplies and quad-port 10GbE/1GbE networking ensure uptime
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.6GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 384GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 5.760,00 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
How do I install drives in the 8SFF bays and what step is often missed?
Slide each 2.5-inch drive into a bay until the latch clicks, then create a virtual disk in the PERC H730 BIOS before the OS sees any volume.
Which component will need replacement first under continuous operation?
The two 495 W power supplies are the first field-replaceable units to wear out under sustained load.
What thermal limit appears first when both 14-core CPUs run at 2.6 GHz continuously?
The 495 W power-supply rating caps total system draw before CPU throttling activates.
