DELL
DELL PowerEdge R640 4LFF Xeon Silver 4214 2.2GHz 12C 128GB DDR4 No Drive
A 1U rack server holding four 3.5-inch drives, with a 12-core Xeon Silver 4214 at 2.2GHz and 128GB DDR4 ECC memory
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.2GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size128GB
- 12-core Xeon Silver 4214 at 2.2GHz handles demanding workloads
- 128GB DDR4 ECC registered memory supports large datasets
- PERC H740P RAID controller protects data integrity
- Four 3.5-inch drive bays ready for SATA storage
- iDRAC9 Enterprise license enables remote management
Dell PowerEdge R640 4LFF Server
This Dell PowerEdge R640 is a 1U rack-mount server configured with four 3.5-inch drive bays. It ships with a single Intel Xeon Silver 4214 processor running at 2.2 GHz with 12 cores and 128 GB of DDR4 ECC registered memory. A PERC H740P RAID controller and a dual-port 10 GbE 562T adapter are installed. The unit includes two 750 W power supplies and iDRAC9 Enterprise remote management.
Suits single-socket deployments needing 3.5-inch
This configuration fits workloads that require a single Xeon Silver 4214 and room for four large-form-factor SATA drives. Buyers who need a second processor for higher thread counts should look elsewhere. Systems requiring drives smaller than 3.5 inches or memory types other than DDR4 are not supported by this chassis. The installed 128 GB capacity leaves headroom below the 7.68 TB maximum.
Single Xeon Silver 4214 at 2.2 GHz with 12 cores
The processor is the primary performance determinant for this server. One CPU is installed in a socket that supports up to two processors. Clock speed is fixed at 2.2 GHz with 16.5 MB cache per chip. Adding a second matching Xeon 4214 would double the core count. Verify that your workload scales within a 12-core single-socket envelope before purchasing.
Points forts
- 12-core Xeon Silver 4214 at 2.2GHz handles demanding workloads
- 128GB DDR4 ECC registered memory supports large datasets
- PERC H740P RAID controller protects data integrity
- Four 3.5-inch drive bays ready for SATA storage
- iDRAC9 Enterprise license enables remote management
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.2GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 128GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 7.68TB |
| Hard Drive (Installed) | 4,00 |
| Storage Controller | Dell PERC H740P Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC9 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
How can I confirm the PERC H740P RAID controller is operational after installation?
During POST the controller initialisation message appears and the iDRAC9 Enterprise dashboard reports the H740P as healthy with current firmware.
Which components ship with the R640 4LFF and which must be sourced separately?
The unit includes one Xeon Silver 4214 processor, 128GB DDR4 ECC registered memory, PERC H740P controller, dual 750W power supplies, 10Gb 2-port 562T adapter and iDRAC9 Enterprise; 3.5" drives and rail kit are not included.
Should I choose the single-processor 128GB configuration or add a second CPU and more memory?
The chassis supports up to two processors and 7.68TB total memory; select the second CPU and additional DDR4 modules only if your workloads need more than 12 cores or exceed 128GB capacity.
