Silver 2U rack server with bezel, 24 front drive trays, rails visible

DELL

DELL PowerEdge R730xd 24-Bay 2.5" 2U Rack Server 2x Xeon E5-2699 v4 2.2GHz 22-Core 64GB DDR4 H730

SKU CH-GEEN-KAEZZ

2U rack server with dual 22-core Xeon processors at 2.2 GHz, 64 GB DDR4 memory, H730 RAID controller and 24 hot-swap 2.5-inch drive trays

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3
  • Dual 22-core Xeons at 2.2 GHz deliver 44 cores for heavy compute
  • 64 GB DDR4 ECC memory supports large virtualisation workloads
  • PERC H730 RAID controller enables RAID 0/1/5/6/10/50/60 data protection
  • 24 front 2.5-inch SAS/SATA trays provide high-density local storage
  • Quad-port 1 GbE and 10 GbE SFP+ networking plus iDRAC8 Enterprise remote management

24-Bay 2U Rack Server

The Dell PowerEdge R730xd is a 2U rack server designed for dense storage workloads. It ships with dual Intel Xeon E5-2699 v4 processors, each running 22 cores at 2.2 GHz with 3.6 GHz Turbo. The system includes 64 GB of DDR4 registered ECC memory across four 16 GB modules. A PERC H730 controller and quad-port network card provide storage and connectivity for enterprise deployments.

Suited for High-Density Storage Nodes

This configuration fits data warehouses, virtual desktop infrastructure and database clusters that need many drive bays in a compact chassis. The 24 front-accessible 2.5-inch trays accept SAS or SATA drives for large capacity arrays. Organisations requiring GPU compute, fibre-channel networking or single-thread frequency optimisation should evaluate alternative platforms.

PERC H730 1 GB RAID Controller

The installed Dell PERC H730 delivers 12 Gb/s SAS and SATA connectivity with 1 GB cache and battery backup. It supports RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode. This controller determines which drive types and RAID levels are available, making it the key specification for storage architects planning the array layout.

Points forts

  • Dual 22-core Xeons at 2.2 GHz deliver 44 cores for heavy compute
  • 64 GB DDR4 ECC memory supports large virtualisation workloads
  • PERC H730 RAID controller enables RAID 0/1/5/6/10/50/60 data protection
  • 24 front 2.5-inch SAS/SATA trays provide high-density local storage
  • Quad-port 1 GbE and 10 GbE SFP+ networking plus iDRAC8 Enterprise remote management

Caractéristiques

BrandDELL
SeriesPowerEdge R730XD
ModelR730xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores22-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Should I pick the 24-bay 2.5" chassis or a smaller drive count for this R730xd?

The 24-bay 2.5" chassis gives maximum density for SAS or SATA drives; choose it when you need many spindles or SSDs in 2U, otherwise a 12-bay 3.5" variant fits fewer but larger drives.

What does the 2.2 GHz base clock with 3.6 GHz turbo mean for real workloads on dual Xeon E5-2699 v4 CPUs?

Each of the two 22-core processors runs at 2.2 GHz base and can boost to 3.6 GHz, delivering 44 total cores for heavy multithreaded tasks such as virtualization or databases.

How does the PERC H730 12Gb/s SAS/SATA controller limit drive performance in practice?

The H730 caps each drive at 12 Gb/s SAS or 6 Gb/s SATA, supports RAID 0/1/5/6/10/50/60 plus pass-through, and uses its 1 GB cache with battery backup for write acceleration.
