Silver 2U rack server front with twenty-four 2.5 inch drive bays and bezel

DELL

DELL PowerEdge R730xd 24 Bay 2.5" 2U Rack Server 2x Xeon E5-2699 v4 2.2GHz 22 Core 64GB DDR4

SKU CH-Z6AV-CJ1AT

A 2U rack server with 24 2.5-inch drive bays, dual 22-core Xeon processors at 2.2 GHz, 64 GB DDR4 memory, PERC H730 RAID controller, quad-port networking and redundant 750 W power supplies

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 64GB

HDD 2 x 300GB 10K SAS

  • Dual Xeon E5-2699 v4 22-core CPUs deliver 44 threads for heavy compute
  • 64 GB DDR4 2400 MHz ECC memory supports large virtualised workloads
  • PERC H730 1 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60
  • 24-bay 2.5" SAS chassis fits dense storage in 2U rack space
  • Dual 750 W platinum PSUs with iDRAC8 Enterprise ensure resilient remote management

Dual Xeon E5-2699 v4 22-core server

The Dell PowerEdge R730xd is a 2U rack server equipped with two Intel Xeon E5-2699 v4 processors, each running at 2.2 GHz with 22 cores and a 3.6 GHz turbo. It ships with 64 GB of DDR4 2400 MHz registered ECC memory across four 16 GB modules and includes a PERC H730 1 GB RAID controller supporting RAID 0, 1, 5, 6, 10, 50, 60 and pass-through modes.

24-bay 2.5" SAS/SATA storage density

This configuration suits organisations that need high drive density in a 2U form factor, offering 24 front-accessible 2.5-inch bays for SAS or SATA drives. Two 300 GB 10K SAS drives are installed, and the quad-port network daughter card provides two 1 GbE and two 10 Gb SFP+ connections. Buyers who require more than two processors, GPU compute slots or storage interfaces not listed here should consider other platforms.

Max 1.5 TB DDR4 across 24 slots

The system supports up to 1.5 TB of DDR4 memory using all 24 DIMM slots, so the installed 64 GB can be expanded significantly for memory-intensive workloads. Dual 750 W platinum power supplies, iDRAC 8 Enterprise remote management, ready rails and a front bezel complete the package.

Points forts

  • Dual Xeon E5-2699 v4 22-core CPUs deliver 44 threads for heavy compute
  • 64 GB DDR4 2400 MHz ECC memory supports large virtualised workloads
  • PERC H730 1 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60
  • 24-bay 2.5" SAS chassis fits dense storage in 2U rack space
  • Dual 750 W platinum PSUs with iDRAC8 Enterprise ensure resilient remote management

Caractéristiques

BrandDELL
SeriesPowerEdge R730XD
ModelR730xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores22-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What does the 12 Gb/s SAS storage controller cap in practice?

The Dell PERC H730 controller runs at 12 Gb/s SAS/SATA and supports RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode.

What physical space and hardware are needed to mount this 2U server?

The chassis is 2U high and includes Ready Rails and a front bezel for rack installation.

How are the CPUs and memory installed, and what step is often missed?

Two Xeon E5-2699 v4 processors are pre-installed in the LGA 2011-3 sockets; the 64 GB DDR4 2400 MHz registered ECC memory occupies four of the 24 DIMM slots, so remaining slots must be populated in the correct channel order for full performance.
