Silver 2U rack server front with 24 drive bays and bezel

DELL

DELL PowerEdge R730xd 2U rack server 2× Xeon E5-2640 v3 2.6GHz 8-core 256GB DDR4 24× 300GB SAS H730

SKU CH-XZDG-VC9F8

A 2U rack server with dual 2.6 GHz 8‑core Xeon CPUs, 256 GB DDR4, a PERC H730 controller and 24× 300 GB SAS drives

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.60 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 256GB

HDD 24 x 300GB 10K SAS

  • Dual 8-core Xeon processors at 2.6 GHz with 3.4 GHz turbo for heavy compute
  • 256 GB DDR4 ECC memory across eight 32 GB modules for large datasets
  • PERC H730 controller with 1 GB cache supporting RAID 0/1/5/6/10/50/60
  • Twenty-four 300 GB 10K SAS drives in 2.5-inch bays for high-capacity storage
  • Quad-port networking with dual 1 GbE and dual 10 GbE SFP+ for flexible connectivity

Dual-socket Xeon rack server

The Dell PowerEdge R730xd is a 2U rack server built for midsize and large enterprises running data warehouses, e-commerce platforms, virtual desktop infrastructure, databases and high-performance computing workloads. It ships with two Intel Xeon E5-2640 v3 processors, each with eight cores at 2.6 GHz and a 3.4 GHz turbo frequency. The system includes 256 GB of DDR4 2133 MHz registered ECC memory across eight 32 GB modules.

Hot-swap power and dense storage

Redundant 750-watt platinum-efficiency power supplies support hot-swap replacement without downtime. The chassis holds twenty-four 2.5-inch drive bays populated with 300 GB 10 K SAS drives connected through a Dell PERC H730 controller with 1 GB cache and battery backup. The controller supports RAID levels 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode.

Quad-port networking and remote management

A Dell Intel X520/I350 daughter card provides two 1 GbE ports and two 10 Gb SFP+ ports for flexible network connectivity. iDRAC 8 Enterprise enables full out-of-band remote management including virtual console, power control and hardware monitoring. Ready Rails and a front bezel are included for immediate rack installation.

Points forts

  • Dual 8-core Xeon processors at 2.6 GHz with 3.4 GHz turbo for heavy compute
  • 256 GB DDR4 ECC memory across eight 32 GB modules for large datasets
  • PERC H730 controller with 1 GB cache supporting RAID 0/1/5/6/10/50/60
  • Twenty-four 300 GB 10K SAS drives in 2.5-inch bays for high-capacity storage
  • Quad-port networking with dual 1 GbE and dual 10 GbE SFP+ for flexible connectivity

Caractéristiques

BrandDELL
SeriesPowerEdge R730XD
ModelR730xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.60 GHz
CPU SocketLGA 2011-3
Number of CPU Cores8-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size256GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How are the 24× 300 GB SAS drives installed in the 2.5" bays, and which step is often missed?

Slide each drive into a hot-swap carrier until the latch clicks, then press the carrier into the bay until the lever locks; the step often missed is fully engaging the carrier lever so the drive connects to the 12 Gb/s backplane.

What maintenance will the PERC H730 controller battery need, and when?

The 1 GB cache battery on the H730 controller typically requires replacement every three to five years; the iDRAC 8 Enterprise console will log a warning when the battery capacity drops below the threshold.

What thermal limit appears first when both Xeon E5-2640 v3 CPUs run at 3.4 GHz turbo under sustained load?

The 2 U chassis relies on dual 750 W platinum power supplies and high-speed fans; under continuous turbo the inlet-temperature limit of 35 °C is reached first, triggering CPU throttling to protect components.
