Silver 2U rack server with front bezel, twenty-four 2.5-inch drive bays and dual hot-swap power supplies

DELL

DELL PowerEdge R730xd 2U rack server 2x Xeon E5-2699 v3 2.3GHz 18-core 64GB DDR4 2x 400GB SSD

SKU CH-PWHF-T5GD7

Dual 18-core Xeon 2.3 GHz server with 64 GB DDR4, H730 RAID, two 400 GB SSDs and quad-port 1/10 GbE in a 24-bay 2U chassis

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 2011-3
  • Dual 18-core Xeon processors at 2.3 GHz with 3.6 GHz turbo for compute-intensive workloads
  • 64 GB DDR4 2133 MHz registered ECC memory supporting up to 1.5 TB capacity
  • PERC H730 1 GB controller enabling RAID 0 1 5 6 10 50 60 for data protection
  • Quad-port networking with dual 1 GbE and dual 10 Gb SFP+ for flexible connectivity
  • Redundant 750 W platinum power supplies and hot-swap bays for continuous operation

Dense 2U compute node

The PowerEdge R730xd packs two 18-core Xeon processors running at 2.3 GHz into a 2U rack chassis with 24 front-accessible 2.5-inch drive bays. Sixty-four gigabytes of DDR4 ECC memory and a PERC H730 controller with 1 GB cache support RAID 0, 1, 5, 6, 10, 50 and 60. Dual 750 W platinum power supplies and iDRAC 8 Enterprise remote management come standard.

Suited to storage-heavy workloads

This server targets databases, virtual desktop infrastructure and data-warehouse nodes that benefit from high core counts and abundant drive slots. The quad-port 1 GbE and 10 Gb SFP+ daughter card handles mixed traffic without extra cards. Buyers who need more than two sockets or who rely on GPU acceleration should evaluate alternative platforms.

Twenty-four drive bays decide fit

The defining specification is the 24-bay 2.5-inch front panel that lets you populate up to 24 SATA or SAS devices behind a single RAID controller. If the workload requires fewer drives or a smaller chassis, a different form factor will save rack space and power.

Points forts

  • Dual 18-core Xeon processors at 2.3 GHz with 3.6 GHz turbo for compute-intensive workloads
  • 64 GB DDR4 2133 MHz registered ECC memory supporting up to 1.5 TB capacity
  • PERC H730 1 GB controller enabling RAID 0 1 5 6 10 50 60 for data protection
  • Quad-port networking with dual 1 GbE and dual 10 Gb SFP+ for flexible connectivity
  • Redundant 750 W platinum power supplies and hot-swap bays for continuous operation

Caractéristiques

BrandDELL
SeriesPowerEdge R730XD
ModelR730xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA
SSD (Installed)2 x 400GB SATA SSD
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What rack space must I reserve for the 2U PowerEdge R730xd?

The server occupies a standard 2U rack height; ensure your cabinet has at least 2U of clearance and supports the included ready rails for installation.

Can the PERC H730 controller manage my existing SATA drives?

Yes, the Dell PERC H730 1GB controller supports both SAS and SATA drives, so older SATA HDDs or SSDs can be added to the 24-bay chassis alongside the installed 400GB SSDs.

How do I confirm the two Xeon E5-2699 v3 processors are recognised after power-on?

During POST the system will display two 18-core CPUs at 2.30 GHz, and iDRAC 8 Enterprise will show 64GB of DDR4 memory and both processors in the hardware inventory.
