DELL
DELL PowerEdge R740 2U rack server 1× Gold 6148 20C 2.4GHz 64GB DDR4 2× 300GB SAS H730P
A 2U rack server with a 20‑core Gold 6148 processor at 2.4 GHz, 64 GB DDR4, dual 300 GB 10K SAS drives and an H730P RAID controller
- TypeRack
- Rack Height2U
- CPU TypeIntel
- Installed Memory Size64GB
- Hard Drive (Installed)2x 300GB 10K SAS
- Storage ControllerH730P
- 20-core Intel Gold 6148 at 2.4 GHz for heavy compute workloads
- 64 GB DDR4 in four 16 GB modules at 2666 MT/s
- H730P RAID controller with 2× 300 GB 10 K SAS drives
- Up to eight PCIe Gen 3 slots for expansion cards
- iDRAC9 Enterprise plus dual 10 Gb and dual 1 Gb Ethernet
Target Workloads
The Dell PowerEdge R740 is a 2U rack server built around a single Intel Gold 6148 processor with 20 cores at 2.4 GHz. It suits virtualisation hosts, database nodes and compute clusters that need strong multi-thread performance in a compact form factor. The included iDRAC9 Enterprise enables full remote lifecycle management.
Memory and Storage Headroom
The system ships with 64 GB of DDR4 across four 16 GB modules running at 2666 MT/s, leaving ample DIMM slots for expansion. Two 300 GB 10K SAS drives sit behind an H730P RAID controller, while the chassis provides eight 2.5-inch bays for additional capacity. Storage grows until the bay limit is reached.
Build Integration
Up to eight PCIe Gen 3 slots accommodate extra network cards, GPU accelerators or storage controllers. An Intel X550 NDC delivers two 10 Gb RJ45 and two 1 Gb RJ45 ports for flexible networking. Dual 1100 W redundant power supplies keep the platform running during a unit failure, and rails plus bezel are included for rack mounting.
Points forts
- 20-core Intel Gold 6148 at 2.4 GHz for heavy compute workloads
- 64 GB DDR4 in four 16 GB modules at 2666 MT/s
- H730P RAID controller with 2× 300 GB 10 K SAS drives
- Up to eight PCIe Gen 3 slots for expansion cards
- iDRAC9 Enterprise plus dual 10 Gb and dual 1 Gb Ethernet
Caractéristiques
| Brand | DELL |
|---|---|
| Model | R740 |
| Type | Rack |
| Rack Height | 2U |
| CPU Type | Intel |
| Installed Memory Size | 64GB |
| Hard Drive (Installed) | 2x 300GB 10K SAS |
| Storage Controller | H730P |
| Max HDD Capacity | 8x 2.5" Drive Bays |
| Remote Management | iDRAC9 Enterprise |
Questions sur cet article
Will my existing SAS drives work with the H730P controller in this R740?
The H730P controller supports SAS drives and the chassis provides eight 2.5-inch bays for them.
How can I confirm the Gold 6148 processor and 64GB DDR4 are recognised after installation?
Check the iDRAC9 Enterprise interface or BIOS; both will show the 20-core 2.4GHz CPU and four 16GB PC4-2666 modules.
Which items ship with the server and what must I source separately?
The box includes the 2U chassis, bezel, rails, power cords, 1100W redundant PSU, two 300GB 10K SAS drives, and the H730P controller; additional drives or PCIe cards are not included.
